Sharp LC-42D43U User Manual

LC-42D43U
2 – 5
19.Remove the 6 lock screws and detach the Lug Angle Top (L)(R).
20.Remove the 3 lock screws and detach the Lug Angle Top (C).
21.Remove the 9 lock screws and detach the Lug Angle Bottom.
22.Remove the LCD Panel Module.
21
Lug Angle Bottom
Lug Angle Top LLug Angle Top R
Lug Angle Top Center
19
2019
