LC-42D62U/LC-62C42U
4 – 1
LC-42D62U/LC-62C42U
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] REMOVING OF MAJOR PARTS
1. Remove the SD Card Cover.
2. Remove the 4 lock screws and detach the Stand Base Ass'y.
3. Remove the 12 lock screws, 5 lock screws and detach the Rear Cabinet.
SD Card Cover
1
2
3
3
Stand Base Ass'y
Rear Cabinet
