PARTS GUIDE
CONTENTS
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-42D62U/LC-62C42U
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
Note:
The reference numbers on the PWB
are arranged in alphabetical order.
No. S86V9LC42D62U
LC-42D62U
LC-62C42U
MODELS
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES (NOT
REPLACEMENT ITEM)
[2] LCD PANEL (NOTE: THE PARTS
HERE SHOWN ARE SUPPLIED AS
AN ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKD934FM03/04 (LC-42D62U/
LC-62C42U) (MAIN Unit)
[4] CABINET AND MECHANICAL
PARTS
[5] SUPPLIED ACCESSORIES
[6] PACKING PARTS (NOT
REPLACEMENT ITEM)
[7] SERVICE JIGS (USE FOR
SERVICING)
