LC-42D62U/LC-62C42U
4 – 5
19.Remove the 4 lock screws and detach the Tray Fixing Angle (L)(R).
20.Remove the 7 lock screws and detach the Lug Angle Top.
21.Remove the 8 lock screws and detach the Lug Angle Bottom.
22.Remove the LCD Panel Module.
Tray Fixing Angle (R)
Tray Fixing Angle (L)
19
19
19
20
20
20
20
20
21
21
21 21
21
21
19
Lug Angle Top
Lug Angle Bottom
