LC-42/46/52D85X
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
Q107 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R105 VRS-CY1JF393JY AA J Resistor, 39k 1/16W Metal Oxide
R108 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R109 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R117 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R121 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R122 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R123 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R135 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Control
SLD101 PSLDPA076WJFW AD N J Shield Case
[5] DUNTKE266FM03 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode, MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug, 5pin (KM)
R151 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor, 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH-UP
S152 QSW-K0003AJZZ+ AB J Switch, CH-DOWN
S153 QSW-K0003AJZZ+ AB J Switch, INPUT
S154 QSW-K0003AJZZ+ AB J Switch, VOL-UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL-DOWN
S156 QSW-K0003AJZZ+ AB J Switch, MENU
S157 QSW-K0003AJZZ+ AB J Switch, POWER
[6] DUNTKE976FM01 (LC-42D85X)/DUNTKE976FM02 (LC-46D85X)/DUNTKE976FM03 (LC-52D85X) (MAIN
Unit)
C1128 VCAAPE1CJ686MY AE J Capacitor, 68 16V Electrolytic
C1501 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1502 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1503 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1504 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1505 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1506 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1507 RC-KZA195WJZZY AB J Capacitor, 10 10V Ceramic
C1508 RC-KZA195WJZZY AB J Capacitor, 10 10V Ceramic
C1509 VCKYCZ1HB221KY AA J Capacitor, 220p 50V Ceramic
C1510 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1511 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1512 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1513 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1514 VCERML1CN106MY AC J Capacitor, 10 16V Electrolytic
C1515 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1516 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1517 RC-KZA195WJZZY AB J Capacitor, 10 10V Ceramic
C1521 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1522 RC-KZA510WJPZY AB J Capacitor, 10 16V Ceramic
C1523 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1524 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1525 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1526 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C1531 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1532 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1534 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1538 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1540 VCAAPE0JJ227MY AE J Capacitor, 220 6.3V Electrolytic
C1543 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1544 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1545 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1546 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1547 VCKYCZ1CF104ZY AA J
Capacitor, 0.1 16V Ceramic
C1548 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1551 RC-KZA195WJZZY AB J Capacitor, 10 10V Ceramic
C1578 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1579 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1582 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1583 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1586 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1587 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1589 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1591 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1592 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1596 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
C1597 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1599 VCKYCZ1HB102KY AB J Capacitor, 1000p 50V Ceramic
C1608 RC-KZA195WJZZY AB J Capacitor, 10 10V Ceramic
C1613 VCKYCZ1CF104ZY AA J Capacitor, 0.1 16V Ceramic
[4] DUNTKE264FM03 (R/C, LED Unit)
