LC-42/46/52D85X
23
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
IC7507 VHICE6353++-1Q AY J IC, WJCE6353 882206
IC7508 VHIBA7655AF-1Y AG J IC, BA7655AF-E2
J1701 QJAKGA122WJZZ AD J Jack
J1702 QJAKGA122WJZZ AD J Jack
J1703 QJAKGA115WJQZ AE J Jack
J1704 QJAKGA122WJZZ AD J Jack
J1705 QJAKGA115WJQZ AE J Jack
L402 RCILPA154WJZZY AE J Coil
L501 VPSBN100J1R2NY AB J Coil, Peaking 10µH
L502 VPSBN100J1R2NY AB J Coil, Peaking 10µH
L504 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
L1303 RCILPA897WJZZY AD J Coil
L1304 RCILPA897WJZZY AD J Coil
L1305 RCILPA897WJZZY AD J Coil
L1306 RCILPA897WJZZY AD J Coil
L7502 VPCNN100J1R6NY AB J Coil, Peaking 10µH
L7503 VPCNN120J1R9NY AB J Coil, Peaking 12µH
L7504 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
L7505 VPCNN330J4R2NY AC J Coil, Peaking 33µH
L7506 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
L7509 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
L7510 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
L7511 VPSBN2R2JR54NY AB J Coil, Peaking 2.2µH
LUG501 QLUGHA009WJZZY AC J Lug
LUG502 QLUGHA009WJZZY AC J Lug
LUG503 QLUGHA009WJZZY AC J Lug
LUG504
QLUGHA009WJZZY AC J Lug
LUG505 QLUGHA009WJZZY AC J Lug
LUG506 QLUGHA009WJZZY AC J Lug
P401 QPLGNA175WJZZY AE J Plug, 6pin (PE)
P501 QPLGNA349WJZZY AE J Plug, 15pin (VD)
P1301 QPLGNA160WJZZY AD J Plug, 4pin (SP)
P7501 QPLGNA342WJZZY AD J Plug, 8pin (FE)
Q402 VSRSS040P03-1Y AE J Transistor, RSS040P03TB
Q407 VSDTC114EE/-1Y AB J Transistor, DTC114EETL
Q516 VS2SC2735//1EY AC J Transistor, 2SC2735JC21TL
Q518 VS2SC2735//1EY AC J Transistor, 2SC2735JC21TL
Q520 VS2SC2735//1EY AC J Transistor, 2SC2735JC21TL
Q521 VSKRC404E++-1Y AB J Transistor
Q1302 VSDTC614TK+-1Y AB J Transistor, DTC614TKT146
Q1401 VSDTC614TK+-1Y AB J Transistor, DTC614TKT146
Q1402 VSDTC614TK+-1Y AB J Transistor, DTC614TKT146
Q1701 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
Q1702 VSDTC314TK/-1Y AC J Transistor, DTC314TKT146
Q1703 VS2SA1530AR-1Y AB J Transistor, 2SA1530A-T112-1R
Q1704 VS2SA1530AR-1Y AB J Transistor, 2SA1530A-T112-1R
Q7501 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7504 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7505 VS2SA1530AR-1Y AB J Transistor, 2SA1530A-T112-1R
Q7506 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q7507 VSRN4904///-1Y AB J Transistor, RN4904(TE85L,F)
R402 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R408 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R409 VRS-CY1JF333FY AA J Resistor, 33k 1/16W Metal Oxide
R410 VRS-CY1JF113FY AA J Resistor, 11k 1/16W Metal Oxide
R415 VRS-CY1JF512JY AA J Resistor, 5.1k 1/16W Metal Oxide
R420 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R423 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R430 VRS-CY1JF432FY AA J Resistor, 4.3k 1/16W Metal Oxide
R431 VRS-CY1JF182FY AA J Resistor, 1.8k 1/16W Metal Oxide
R432 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R438 VRS-CY1JF333JY AA J Resistor, 33k 1/16W Metal Oxide
R501 VRS-TQ2EF680JY AA J Resistor, 68 1/4W Metal Oxide
R503 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R534 VRS-CY1JF473FY AA J Resistor, 47k 1/16W Metal Oxide
R535 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R536 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R537 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R538 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R539 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R540 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
R565 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R566 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R569 VRS-TQ2EF750JY AA J Resistor, 75 1/4W Metal Oxide
R570 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R571 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R572 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R574 VRS-TQ2EF750JY AA J Resistor, 75 1/4W Metal Oxide
R575 VRS-TQ2EF750JY AA J Resistor, 75 1/4W Metal Oxide
R580 VRS-CY1JF103FY AA J Resistor, 10k 1/16W Metal Oxide
R586 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R587 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R589 VRS-CY1JF103FY AA J Resistor, 10k 1/16W Metal Oxide
R592 VRS-CY1JF220FY AA J Resistor, 22 1/16W Metal Oxide
R595 VRS-CY1JF101FY AA J Resistor, 100 1/16W Metal Oxide
[7] DUNTKE977FM01 (SUB Unit)
