LC-42/46/52D85X
28
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS (LC-42D85X)
1 CCABAB825WJ49 BN N V Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 Not Available - - Front Cover
1-3 Not Available - - Badge, SHARP
1-4 HDECQA777WJ1A AC J LED Decoration
1-5 HDECSA028WJ3C AS N V Shine Trim
1-6 HPNLSA226WJ4A N V Speaker Sheet
1-7 PSPAHB223WJ4Z AC J Spacer, x4
1-8 PSPAHB381WJZZ AC J Spacer, x2
1-9 PSPAZB544WJ4Z AD J Tape (for W-Side), x6
1-10 PSPAZB541WJ4Z AB J Tape (for Front Cover)
1-11 PSPAZB542WJ4Z AB J Tape (for Front Cover)
1-12 PSPAZB543WJ4Z AC J Tape (for Front Cover), x2
1-13 QEARZA116WJZZ AM J Cloth Tape, x2
1-14 QEARZA117WJZZ AE J Cloth Tape, x4
1-15 XJPS730P08WS0 AA J Screw (for Front Cover), x3
2 CCABBB401WJ43 BF N V Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 GCOVAC518WJ4Z AE J Hole Cover, x4
2-3 HINDPC551WJ4A AF J Terminal Label (Bottom)
2-4 PRDARA523WJ4W AD N J Radiator
2-5 PSPAHB362WJ4Z AD N J Spacer (for CAB-B), x2
3 R1LK420D3LZ6DW N J 42"LCD Panel Module Unit
4 CCOVAC392WJ42 AN N J Mini AV Cover Ass'y
4-1 Not Available - N - Mini AV Cover
4-2 HINDPC563WJ4A AD N J Mini AV Label
4-3 JBTN-A676WJ4A AE N J Operation Button
5 CANGKB173WJ43 AN N V Terminal Angle Side Ass'y
5-1 Not Available - - Terminal Angle Side
5-2 HINDPD098WJ4A AE N V Terminal Angle Label
5-3 HINDPC627WJ4A AC J Terminal Angle Label-A
6 DUNTKE188FM05 BB N V MINI-AV Unit
7 DUNTKE264FM03 AP N V R/C, LED Unit
8 DUNTKE266FM03 AG N V
KEY Unit
9 DUNTKE976FM01 N V MAIN Unit
10 DUNTKE977FM01 N V SUB Unit
11 RDENCA237WJQZ BT N V POWER Unit
12 RUNTKA341WJQZ AY N V AC INLET Unit
13 GCOVAC336WJ4A AL J Bottom Cover
14 HINDPD002WJ4A AD N V Model Label
15 LANGKB187WJ4W AU N J Panel Support Angle, x2
16 LANGKB216WJ4W AF J Mini AV Angle
17 LANGKB238WJ4W AL N V Terminal Angle Bottom
18 LCHSMA386WJ4W AZ N J Tray Chassis
19 LHLDFA036WJKZ AB J Wire Holder (for Tray), x3
20 LHLDW1033CE00 AA J Wire Holder, x2
22 LHLDWA080WJKZ AB J Wire Holder, x2
23 LHLDWA133WJKZ AC J Wire Holder, x3
24 LHLDWA143WJKZ AC J Wire Holder, x6
25 LHLDWA151WJKZ AB J Wire Holder, x5
26 LHLDWA163WJKZ AC J Wire Holder, x10
27 LHLDWA172WJKZ AD J Wire Holder
28 LX-TZ3011CEF7 AB J Screw (for SP), x4
29 NSFTZ0134CEFW AD N V Shaft, x4
30 PCOVP2605WJN1 AX N J Control Shield
34 PMLT-A521WJZZ AD N J Absorber
35 PRDARA482WJ4W AP N J Main PWB Radiator
36 PRDARA513WJFW AX N J Radiator
37 PSLDMB158WJ4W AL J Main Shield
38 PSLDMB159WJ4W AK J AV Shield
39 PSLDMB179WJ4W AD J Mini AV Shield
40 PSLDMB276WJKZ AE N J Shield, x2
42 PSLDMB278WJKZ AE N J Shield
45 LHLDWA164WJKZ AD J Wire Holder
46 PSLDMB300WJQZ AF J Shield
47 PSPAZB312WJKZ AD J Spacer
48 PSPAZB313WJKZ AC J Spacer, x2
49
PSPAZB611WJKZ AN J Spacer, x2
50 PSPAZB612WJKZ AH J Spacer
51 PSPAZB613WJKZ AD J Spacer, x2
52 PSPAZB614WJKZ AE J Spacer
53 QCNCMA673WJZZ AG N J Connector (80pin)
54 QCNW-F946WJQZ AH N J Connecting Cord (AC)
55 QCNW-F948WJQZ AK N J Connecting Cord (PE)
56 QCNW-F970WJQZ BC J Connecting Cord (LW)
57 QCNW-F988WJQZ AH J Connecting Cord (FR)
58 QCNW-G020WJQZ AG N J Connecting Cord (KM)
59 QCNW-G023WJPZ AM N J Connecting Cord (US)
60 QCNW-G024WJQZ AS N J Connecting Cord (VD)
61 QCNW-G025WJQZ AH J Connecting Cord (SP)
62 QCNW-G026WJQZ AH N J Connecting Cord (LA)
63 LX-BZA207WJF7 AA J Screw, x2
64 QCNW-H943WJQZ AL N V Connecting Cord (LB)
65 QCNW-G237WJQZ AL N J Connecting Cord (RA)
66 QCNW-G387WJQZ AH J Connecting Cord (PD)
