LC-42/46/52D85X
31
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] LCD PANEL UNIT (LC-42D85X)
1 R1LK420D3LZ6DW N J 42"LCD Panel Module Unit
2 Not Available - - Bezel Ass'y
3 CCHSM0031TP02 BN J BL Chassis Ass'y
4 LANGTA468WJFW AE J Ferrite Core Angle
5 RCORFA061WJZZ AG J Ferrite Core, x2
6 RLMPLA011WJN1 AR J Lamp, x22
7 LHLDZ3765TPZZ AL J Lamp Holder, x2(Replace the both at the same time)
8 LHLDZ3769TPZZ AC J Lamp Clip A, x2
9 LHLDZ3770TPZZ AC J Lamp Clip B, x4
10 LHLDZ3771TPZZ AC J Lamp Clip C, x4
11 LHLDZ3772TPZZ AC J Lamp Clip D, x4
12 LHLDZ3773TPZZ AC J Lamp Clip E, x4
13 LHLDZ3774TPZZ AC J Lamp Clip F, x4
14 QSOCFA002WJZZ AD J Lamp Socket, x22
15 PSHEP2838TPZZ AS J Insulation Sheet (for Inverter Unit)
16 TCAUZA031WJZZ AB J Caution Label
17 PMIR-A142WJZZ AZ J Reflection Sheet
18 PSHEPA590WJZZ BQ J Diffusion Plate
19 LHLDFA035WJKZ AB J INVERTER Spacer, x5 (for BL Chassis)
20 RUNTKA367WJN1 BQ J INVERTER Unit
21 RUNTK3843TPZZ BH J INVERTER GND Unit A
22 RUNTK3844TPZZ BH J INVERTER GND Unit B
23 PCOVPA085WJKZ AG J Invasion Prevention Cover A
24 PCOVPA086WJKZ AH J Invasion Prevention Cover B
25 LX-LZA105WJZZ AB J Push Rivet, x4 (for Invasion Prevention Cover)
26 XBPS730P04WS0 AA J Screw, x4 (for INVERTER GND Unit)
27 LX-BZA207WJF7 AA J Screw, x3 (for INVERTER, x2/LCD CONTROL, x1)
28 XBPS730P06WS0 AA J Screw, x2 (for Ferrite Core Angle )
29 LX-BZA196WJF7 AB J Screw, x12 (for Bezel)
30 CPWBY3893TPXP CE J LCD CONTROL Unit
31 QPWBM0566TPZZ AG J FPC
32 QPWBM0574TPZZ AG J FPC
33 PSHEP2933TPZZ AP J Heat Radiation Sheet (for LCD CONTROL Unit)
34
PSHEP2934TPZZ AH J Heat Radiation Sheet (for LCD CONTROL Unit)
