LC-42/46/52D85X
5 – 9
8. STANDBY CAUSE FUNCTIONS
This model is equipped with a STANDBY CAUSE FUNCTIONS which stores the cause of why the unit is turned off and displays it on adjustment pro-
cess mode.
1. NORMAL STANDBY CAUSE
ERROR CODE here indicates cause of standby in normal operation or Function of the Unit.
No display when the unit is turned off with R/C.
Only the latest cause is indicated.
2. ERROR STANDBY CAUSE
ERROR CODE here indicates cause of Error in the unit.
It also indicates accumulated operating times of the unit.
The last five histories are displayed.
1)-5) five histories 1) is the latest.
When there is no error, error code is ‘0’ and no characters appear.
3. MONITOR ERROR CAUSE
When the monitor micom detects an error, ERROR CODE is displayed.
The number of flashing Power LED and OPC LED indicates location of error detected.
This number stores the latest four contents of the error. ‘0’ is displayed when no error.
• NORMAL STANDBY CAUSE
• ERROR STANDBY CAUSE
• MONITOR ERROR CAUSE
Display Code Indication Description
2 NO_OPERT in the cause of “no operation off”
3 NO_SIGNA in the cause of “no signal off”
6 SLEEP_TM in the cause of “SLEEP timer”
8 OFF_232C in the cause of command by RS-232C
Display Code Indication Description
17 E_AVCTMP in the cause of abnormal temperature
Display Error Reason
Power (RED) LED
Blink Times
OPC LED
Blink Times
01 Initial Communication Error 1 Not used
02 Initial Communication Error 2 Cannot receive initial communication from main CPU 3 times 1 time
03 Initial Communication Error 3 Receive initial communication only 3 times 2 times
04 Initial Communication Error 4 To the communication setting reception 3 times 2 times
05 Initial Communication Error 5 To the initialization completion reception 3 times 2 times
06 Initial Communication Error 6 To the notice of version reception 3 times 2 times
07 Initial Communication Error 7 To the notice of start information reception 3 times 2 times
08 Initial Communication Error 8 To the start information answer reception 3 times 2 times
09 Initial Communication Error 9 To the time-out setting reception 3 times 2 times
0A Communication Error A Request Time-out 3 times Off
0B Communication Error B Restart Time-out 3 times 4 times
0C Communication Error C End sequence Time-out Off Off
0D Communication Error D Reserve start Time-out when End seqence Off Off
0E Communication Error E Download Start Time-out 3 times Off
0F Communication Error F Get Time Start Time-out Off Off
10 Communication Error G Not used
11 Communication Error H Watchdog Time-out 3 times 3 times
12 Communication Error I Not used
13 Communication Error J Not used
14 Communication Error K Not used
15 Power (RED) LED Blink 0 Not used
16 Power (RED) LED Blink 1 Lamp Error 1 time Off
17 Power (RED) LED Blink 2 AC_DET Error 2 times 1 time
18 Power (RED) LED Blink 3 Not used
19 Power (RED) LED Blink 4 Not used
1A Power (RED) LED Blink 5 Monitor Temperature Error 5 times Off
1B Power (RED) LED Blink 6 Not used
1C Power (RED) LED Blink 7 Not used
1D Power supply Error 1 PS_ON(DET_10V) Error 2 times 3 times
1E Power supply Error 2 Not used
