Connecting an Audio Amplifier
Connecting an AV Amplifier
HDMI OUT
HDMI
IN
HDMI
OUT
HDMI-certified cable
HD Cable/Satellite set-top box
Back and side
panel inputs
Connecting to External Equipment
Side Panel
Vertical Output
DIGITAL AUDIO INPUT
OPTICAL
Coaxial Cable
When using coaxial cable:
It is possible to output audio through the DIGITAL AUDIO terminal. PCM audio outputs from the
terminal.
• Digital Audio output is not available when using an HDMI input.
• If the image is not in sync with the audio, check the settings of the connected surround system.
• Letting the TV output the audio to an AV amplifier.
To Next Page
