Sharp LC-42SV50U - Connecting a PC

Connecting a PC
Refer to page 43 for a list of PC signals compatible with the TV.
When using HDMI cable (INPUT 1, 2 or 3):
• The HDMI terminals only support digital signal.
When using DVI-HDMI conversion cable (INPUT 1,2,3):
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in
addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3 (HDMI) terminal, connect a Ø 3.5 mm
stereo minijack cable to the AUDIO PC/HDMI terminal.
When using analog RGB cable (PC IN):
20
Connecting to External Equipment
Back and side
panel inputs
HDMI OUT
HDMI-certified cable
DVI OUT
AUDIO
DVI-HDMI conversion cable
Ø 3.5 mm stereo minijack cable
Back and side panel inputs
• When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of PC IN.
AUDIORGB
Ø 3.5 mm stereo minijack cable
Analog RGB cable
(D-sub 15-pin cable or VGA cable)
Back panel
vertical inputs
