LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 55
9. Remove all the connectors from PWBs.
Wire "LA1"
Wire "LC"
Wire "LA1"
Wire "SP-L"
Wire "SP" to WH
Wire "LA1","LC" to WH
Wire "LC" to WH
Wire "LA2","LB","LC" to WH
Wire "LA2","LB","LC" to WH
Wire "LC"
Wire "FR"
Wire "PL"
Wire "LA2"
Wire "LB"
Wire "LA2"
for Wir e "LB","LA2","LC"
