Page 13-1
File No. SG-0000245
Chapter 13 Spare Parts List
PART NO DESCRIPTION LOC QTY REMARK
9LE018467510083 POLYSWITCH 0.75A 8V SMD (1206L075THYR) HF 1 FU5
9LE028024000313 X'TAL 24MHZ 49S 20PF 30PPM -20~70'C LF 1 Y100
9LE030062000130 USB CONN. A TYPE 90' (3AL04S-305-ZC) L-F 1 PU3
9LE030064000070 OPTO CONN. Transmitter (JST1221) L-F 1 PA1
9LE030290200039
(2nd) RCA JACK 1ROW 2I/O 90' (W-R) (RCA215D-01)
LF
1 PA2
9LE030290200270
RCA JACK 2ROW 2I/O 90' (W-R) (WT-04066V2B-06H)
L-F
1 PA2
9LE030290500071
RCA JACK 1R 5IO 90'(GBRWR)(WTJ-032-55V2B-01A)
LF
1 PV1
9LE030310023517
CONN B TO FPC 0.5mm 51P 90'
SMD(196334-51041-3) HF
1 JL2
9LE030410000321
CONN HDMI 19P 90' SMD WITH SPRING
(51U019S-321W-C4R-BA2) LF
3 PH4, PH5,PH6
9LE03351006AF52
SPK 10W 6ohm (1150*650mm) +AL FPTW for LC-65 &
LC55
1
9LE032040000470
POWER CORD 2P POLA. 1500mm 7A
UL/CSA(SP-12/IS-08A) N.M(SH)
1
9LE039050034293
DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23)
L-F
3 DV1,DA1,DA5
9LE039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF 1 DV2
9LE041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF 12
QL1,QA1,QI2,QS3,QA3,QS4,QA4
,QS5,QS6,QH8,QH9,QP10
9LE042020092643 MOSFET P-CH 3.2A 30V ME2303-G SOT-23 HF 1 QP4
9L 043000016609 IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF 1 UH4
9LE043030163045
IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8
LF
1 US4
9LE043060270079 IC LDO 1A ADJ AP1117EG-13 SOT223-3L 3PIN HF 1 UP3
9LE043060414016
IC STEP-DOWN CONV 3A 24V EUP3484SDIR1 SOP-8
HF
1 UP18
9LE043060437039
IC STEP-DOWN CONV 1.5A 5.5V LA8013ACD
SOT-23-5 LF
2 UP15,UP16
9LE0430604260C1
IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-8
LF
1 UP17
9LE043070865615 IC AUDIO OP DRV632PWR TSSOP-14 HF 1 UA2
