Chapter 14 Complete Parts List
LCD TV 55'' SHARP LC-55LE541U FPTW (AUO T550HVN06.0)
Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
1 1 9LE 365501920334 BASE ASS'Y LC-55LE643U P Phantom EA 1
2 1 9LE 170105525010 BASE(ABS 94-HB/T52013)(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 172130030620 TAP. SCREW-TF #3.0*6.0L,Ni G Assembly Pull EA 10
2 11 9LE 172550040720 MAC. SCREW MI M4.0*7.0L, Ni Nylok G Assembly Pull EA 12
2 41 9LE 181304015020 NECK BKT(SGCC 1.6t)(LC-55LE643U)ASS'Y G Assembly Pull EA 1
3 1 9LE 171201027890 NECK SUPPORT BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 2
3 1 9LE 171201028010 NECK INNER(SGCC 2.0t)(LC-55LE643U) G Supplier EA 1
3 1 9LE 171304015020 NECK BKT(SGCC 1.6t)(LC-55LE643U) G Supplier EA 1
3 1 9LE 172500040650 MAC SCREW-MB M4.0*6.0L,BLK_Ni, NYLOK G Supplier EA 2
3 1 9LE 172530040620 MAC. SCREW-MF M4.0*6.0L,NI,NYLOK G Supplier EA 4
2 21 9LE 181304019010 BASE BKT(SGCC 1.6t)(LC-55LE643U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170110000700 BASE FOOT (SILICON RUBBER/ D18.0*2.0t)(447C) G Supplier EA 10
3 1 9LE 171304019010 BASE BKT(SGCC 1.6t)(LC-55LE643U) G Supplier EA 1
1 1 9LE 365502320315 MRO ASS'Y LC-55LE541U_MX P Phantom EA 1
2 1 9LE 192521001730 CORNER BAR(L2400*50*50*5t) G Assembly Pull EA .167
2 1 9LE 192521002090 SLIP SHEET(L1150*W1480*0.9t/OPEN SIDE 1150) G Assembly Pull EA .042
2 1 9LE 192521019440 PAPER SHEET(L1400*W1100*8t) G Assembly Pull EA .084
2 1 9LE 193612000020 FG SHIPPING LBL(#80 art paper)(10cm x 18cm) G Assembly Pull EA .0834
2 1 9LE 193612000030 SHIPPING LBL(#80 art paper)(11cm x 7.5cm) G Assembly Pull EA .0417
2 1 9LE 193613002420 S/N LBL(#80 art paper)(55x15mm) G Assembly Pull EA 1
2 1 9LE 194712008460 CARTON TAPE(L600m*W72mm*0.06t) G Assembly Pull MZ 3.344
2 1 9LE 194725000660 PACKING FILM(L2000m*W500mm*0.0155t) G Assembly Pull MZ 2.169
1 1 9LE 365513920312 PACKING ASS'Y Sharp LC-55LE541U_MX P Phantom EA 1
2 1 9LE 192510016780 EPS FOAM_FRONT(EM55FTR) G Assembly Pull EA 1
2 1 9LE 192510017190 EPS FOAM_TL(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192510017200 EPS FOAM_TR(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192510017210 EPS FOAM_BL(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192510017220 EPS FOAM_BR(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192511005060 EPE BAG(W1350*L950*0.3t)(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192511005080 PE BAG(W600*L450*0.06t)(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 192512023600 CARTON(AE/FLUTE) Sharp LC-55LE541U G Assembly Pull EA 1
2 1 9LE 193611016920 B/C LBL(PET 50#)SHARP LC-55LE541U G Assembly Pull EA 1
2 1 9LE 193613002500 S/N LBL(Black) 40*8(PET 50#) G Assembly Pull EA 1
2 1 9LE 193614006020 CARTON LBL(art paper 80#)(50*15) Sharp G Assembly Pull EA 1
2 1 9LE 365504920393 ACCESSARY ASS'Y Sharp LC-55LE541U_MX P Phantom EA 1
3 1 9LE 032040000470 POWER CORD 2P POLA. 1500mm 7A UL/CSA(SP-12/IS-08A) N.M(SH) G Assembly Pull EA 1
3 1 9LE 060230000010 Battery Zn-Carbon 1.5V AAA(R03UG) TOSHIBA LF G Assembly Pull EA 2
3 *R* 9LE 060250000010 Battery Zn-Carbon 1.5V AAA(R03) MITSUBISHI G Assembly Pull EA 2
3 *R* 9LE 060230000040 Battery Zn-Carbon 1.5V AAA(R03UG(JE)) TOSHIBA LF G Assembly Pull EA 2
3 1 9LE 098003063200 REMOTE IR 37.9KHz 47KEY GJ221 (SHARP) LF G Assembly Pull EA 1
3 1 9LE 172500041050 MAC SCREW-MB M4.0*10.0L,BLK-Ni,NYLOK G Assembly Pull EA 4
3 1 9LE 192511000280 PE BAG (180W*290L*0.04t)(PE-LD)(ACC.-1) G Assembly Pull EA 1
3 1 9LE 192513015830 QSG Sharp LC-55LE541U/LC-65LE541U G Assembly Pull EA 1
