Sharp LC-55LE541U - Page 66

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
3 1 9LE 170104280000 DISPLAY KEY(EM55FTR) G Supplier EA 1
3 1 9LE 170104280030 DISPLAY KEY(HIPS FR/T52013)(LC-65LE643U) G Supplier EA 1
3 1 9LE 170119805010 DISPLAY KEY COVER(HIPS FR/T52013)(EM55FTR) G Supplier EA 1
3 21 9LE 194715009900 FOAM PAD(20.0*5.0*0.3t)(BLK) G Supplier EA 4
2 1 9LE 181201027790 PANEL SUPPORT BKT(SGCC 2.0t)(LC-55LE643U)ASS'Y G Assembly Pull EA 2
3 11 9LE 171201027620 PANEL SUPPORT BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 1
3 1 9LE 171201027810 PANEL HOLDER BKT(SGCC 2.0t)(LC-55LE643U) G Supplier EA 1
3 1 9LE 172500040650 MAC SCREW-MB M4.0*6.0L,BLK_Ni, NYLOK G Supplier EA 4
2 1 9LE 194712000311 ACETATE CLOTH TAPE 27*75mm G Assembly Pull EA 2
2 1 9LE 194712000341 ACETATE CLOTH TAPE 20*20mm G Assembly Pull EA 4
2 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 4
2 1 9LE 194715004200 CR SPONGE (30.0L*20.0W*0.6t) G Assembly Pull EA 4
2 1 9LE 194715009840 CR SPONGE(20.0L*10.0W*6.0t)(BLK) G Assembly Pull EA 1
2 1 9LE 194717000830 Conductive Fabric tape (L50*W20mm) G Assembly Pull EA 1
2 1 9LE 194717001220 Conductive Tape 30*60mm for ESD G Assembly Pull EA 1
2 1 9LE 194717001410 Conductive Tape 30*15mm (L type) for ESD G Assembly Pull EA 1
2 1 9LE 194718002740 Gasket Block L25*W12*2.0H for ESD G Assembly Pull EA 1
2 1 9LE 194719000870 THERMAL PAD(13*13*7.5t) G Assembly Pull EA 1
2 1 9LE 194724001550 MYLAR(FRPP/250*250*0.45t)(BLK)(LC-55LE643U) G Assembly Pull EA 1
2 1 9LE 363202420189 IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) M Assembly Pull EA 1
3 1 9LE 363202420189M IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) MI P Phantom EA 1
4 21 9LE 045112500406 WAFER 1.25mm 4P 180' DIP KINK (M24014) L-F G Assembly Pull EA 1 JR2
4 *R* 9LE 045112500403 WAFER 1.25mm 4P 180' KINK (A1251WV0-4P) L-F G EA 1
4 1 9LE 363202420189T IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) TOP P Phantom EA 1
5 61 9LE 011131015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1 CR7
5 *R* 9LE 011231015117 C/M Multi. 100PF 50V X7R K 0402 G EA 1
5 41 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2 CR5,CR6
5 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G EA 2
5 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G EA 2
5 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 1 CR1
5 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 1
5 71 9LE 013018001654 RES. CF 180ohm 1/16W J 0402 G Assembly Pull EA 1 RR1
5 1 9LE 013047091858 RES. CF 47ohm 1/8W J 0805 G Assembly Pull EA 1 LR1
5 51 9LE 017116711145 PCB IR BD FR4 54*8*1.6t 2L (SHARP A+)(1:20) G Assembly Pull EA 1
5 1 9LE 044040000206 LED White TOP VIEW (LTW-C191UC5) 1.6*0.8*0.55mm SMD HF G Assembly Pull EA 1 LED1
5 1 9LE 098002006050 IR RECEIVER 38KHz 4pin 5.2x4x2.8mm SMD(NS6738S) LF G Assembly Pull EA 1 UR1
5 *R* 9LE 098002006031
IR RECEIVER 38KHz 4pin SMD 5.2x4x2.8mm R1.0(FM-A438FN-
5CN)LF
GEA1
2 1 9LE 365500420304 LCM ASS'Y LC-55LE541U (AUO T550HVN06.0) P Phantom EA 1
3 1 9LE 021505501077 Open cell ASS'Y T550HVN06.0 (AUT) G Assembly Pull EA 1
3 1 9LE 046010020221 A2001-2/A2001-2 10368#26 150mm(B) G/Y HF G Assembly Pull EA 4
3 1 9LE 046011070350 A2512-7/PK242151P2*2 10368#26 350/550(C) HF G Assembly Pull EA 1
3 1 9LE 098102557704 55.55T16.C03 T-CON ASS'Y for T550HVN06.0(AUO) G Assembly Pull EA 1
3 1 9LE 170114000840 PCB HOLDER(MIB-2) G Assembly Pull EA 4
