Sharp LC-60C6500U Service Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[11] SUPPLIED ACCESSORIES/PACKING PARTS (LC-70LE755U/757U/857U/C7500U) (NOT
REPLACEMENT ITEM)
X1 CDAi-A857WJ03 N X Stand Base Ass'y (LC-70LE857U)
X1 CDAi-A875WJ31 N X Stand Base Ass'y (LC-70LE755U/757U/C7500U)
X2 CANGKD781WJ02 N X Support Ass'y (LC-70LE857U)
X2 CANGKD890WJ31 N X Support Ass'y (LC-70LE755U/757U/C7500U)
X3 CCOVAE591WJ31 N X Stand Safety Cover Ass'y (LC-70LE755U/757U/C7500U)
X4 CSAKKA011WJ04 X Stand Screw Ass'y (LC-70LE755U/757U/C7500U)
X4 CSAKKA016WJ02 X Stand Screw Ass'y (LC-70LE857U)
X5 KOPTLA006WJQZ X 3D Glasses (LC-70LE755U/757U/857U)
X6 RRMCGB004WJSA X Remote Control (LC-70C7500U)
X6 RRMCGB005WJSA BG J Remote Control (LC-70LE755U/757U/857U)
X7 TCADEA290WJZZ X Enquete Card
X8 TGAN-B767WJZZ N X Extend Card
X9 TiNS-F700WJN1 N X Operation Manual
X10 TiNS-F777WJZZ N X 3D Glasses Manual (LC-70LE755U/757U/857U)
X11 TMAN-A050WJZZ N X Connection Guide
X12 Not Available - - AAA size Battery, x2
S1 SPAKAA732WJZZ - N - Edge Board (Top) (NOT REPLACEMENT ITEM)
S2 SPAKAA733WJZZ - N - Edge Board (Bottom) (NOT REPLACEMENT ITEM)
S3 SPAKCH104WJZZ - N - Packing Case (LC-70LE757U) (NOT REPLACEMENT ITEM)
S3 SPAKCH110WJZZ - N - Packing Case (LC-70LE857U) (NOT REPLACEMENT ITEM)
S3 SPAKCH115WJZZ - N - Packing Case (LC-70C7500U) (NOT REPLACEMENT ITEM)
S3 SPAKCH163WJZZ - N - Packing Case (LC-70LE755U) (NOT REPLACEMENT ITEM)
S3 SPAKCH246WJZZ - N - Packing Case (LC-70LE755U) (NOT REPLACEMENT ITEM)
S4 SPAKCH105WJZZ - N - Packing Case (Bottom) (LC-70LE857U) (NOT REPLACEMENT ITEM)
S4 SPAKCH111WJZZ - N - Packing Case (Bottom) (LC-70LE857U) (NOT REPLACEME
S5 SPAKPB733WJZZ - - Polyethylene Bag (NOT REPLACEMENT ITEM)
S6 SPAKXD919WJZZ - N - Packing Form (Top) (LC70LE755U/ÇV57U/C7500U) (NOT REPLACEMENT ITEM)
S6 SPAKXD926WJZZ - N - Packing Form (Top) (LC70LE857U) (NOT REPLACEMENT ITEM)
S7 SPAKXD920WJZZ - N - Packing Form (Bottom) (LC70LE755U/ÇV57U/C7500U) (NOT REPLACEMENT ITEM)
S7 SPAKXD927WJZZ - N - Packing Form (Bottom) (LC70LE857U) (NOT REPLACEMENT ITEM)
S8 SSAKA0101GJZZ - - Polyethylene Bag (NOT REPLACEMENT ITEM)
S9 TLABKA009WJZZ - - Case No. Label (NOT REPLACEMENT ITEM)
[12] SERVICE JIG (USE FOR SERVICING)
N QCNW-C222WJQZ AW J Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ J
Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2 (LC-60/
70LE755U/757U/857U)
N QCNW-F676WJQZ BH J Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LV)
N QCNW-M539WJQZ BC J Connecting Cord L=1000mm 24-24/4pins, Power-Main/LCD Control (PD)
