LC-60LE651 MK2
LC-60LE652 MK2
CABINET AND MECHANICAL PARTS LISTING
REF No. PARTS DESCRIPTION *
Price code
1 CCABAC976WE02 KS-CAB-A LC60LE65*E MK2 P BD
2 GCABAC976WJ1B FRONT CABINET P --
3
DUNTKG135FM12 ADJUST MAIN UNIT (60LE651) P BZ
DUNTKG135FM11 ADJUST MAIN UNIT (60LE652) P BZ
4 RUNTKB074WJQZ POWER UNIT WITH LED DRIVER 60” SHARP P BP
5 CDAI-A863WJ02 KS-STAND LC60LE65*E MK2 P --
6 HDECQB797WJ1A PIRAMID LIGHTING DIFFUSER (CHLDFA077WE02 ctrl button set) P AD
7 DUNTKG221WE02 KEY UNIT 60” LE65x (CHLDFA077WE02 ctrl button set) P AX
8 LHLDFA077WJ1A CONTROL HOLDER LE65x (CHLDFA077WE02 ctrl button set) P AF
9 GCABBC170WJ1A REAR CABINET LC60LE65* P BP
10 GCOVAE525WJ1A AC CORD COVER P AE
11 LANGKD809WJFW STAND BRACKET (60LE650_750) P AT
12 CANGKD484WJ43 KS VESA ANGLE P --
13
LANGKD726WJFW CHASSIS BRACKET (60LE651) P AR
LANGKD937WJFW CHASSIS BRACKET (60LE652) P AR
14 HINDPE919WJ1A TERMINAL INDICATION PLATE (SIDE) 60LE65* P AD
15
HINDPE891WJ1A CONNECTORS LABEL (60LE651) P AE
HINDPE892WJ1A CONNECTORS LABEL (60LE652) P AE
16 PSPANA044WJKZ POW PWB SPACER P AB
17 DUNTLG222FM51 CONTROL UNIT PANEL LE65x (T-CON) P BR
18 LHLDWA303WJKA WIRE HOLDER (for Rear Cabinet location) P AC
19 QCNW-N271WJQZ PD WIRE 14 PINS 60”/70” (SERIES 65x/75x) P AM
20 QCNW-N272WJQZ LV WIRE 51 PINS 60”MODELS TOTOKU P AM
21 QCNW-N273WJQZ LW WIRE 41 PINS 60” MODELS TOTOKU P AM
22 QCNW-N270WJQZ
RA WIRE MODEL 60” (SERIES 65x)
PAM
23 QCNWN2731TPZZ CABLE FFC(80P:MDL-CTL) P AF
24 LHLDWA294WJUZ WIRE HOLDER P AB
25 R1JE600D3GV2AY 60 LCD Module JE600D3GV2AY P DX
26
QACCKA055WJPZ AC CORD P AM
QACCBA106WJPZ AC CORD FOR UK P
27 RSP-ZA634WJZZ SPEAKER SET FOR 60” (x2 WITH CABLE) P AZ
28 TLABNC117WJZZ
MODEL LABEL (DLAB-G358WE01 set LE651EMK2/
DLAB-G359WE01 set LE651KMK2/ DLAB-G360WE01 set LE652EMK2)
PAA
29 TLABZD485WJZZ CE ENERGY LABEL (60LE65*) P AG
30 NSFTZA459WJF7 TRAY SHAFT P AC
31 XBPS730P06WS0 SCREW PAN ST ZN M3x6 P AA
32 XEPS730P08WS0 SCREW PAN ST ZN 3x8 P AA
33 LX-BZA429WJF8 STAND SCREW M4x10 BK (CSAKAA186WJ01 BAG ) P AB
