Sharp LC-60LE745U - Main PWB Mounting Diagram

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
4 – 15
The following is a drawing mounting the main PWB Ass’y on the backlight chassis. (The parts indicated by -> are the access holes for confirmation.)
(Main PWB Ass’y => State where the shielded case and RF terminal angle are mounted on the main PWB)
