Sharp LC-60LE745U User Manual

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
iv
LC60LE745U
ServiceManual

OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF953FM01) in case of IC3103 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
No. PARTS CODE DESCRIPTION
N DKEYMF953FM01 MAIN Unit
N DUNTKF800FM53 KEY Unit
N DUNTKF975FM04 LCD CONTROL Unit (LC-60/70LE745, 60/70C7450)
N DUNTKF961FM02 LCD CONTROL Unit (LC-60LE845/847/C8470)
N DUNTKF961FM01 LCD CONTROL Unit (LC-70LE845/LE847/C8470)
N DUNTKG014FM02 ICON Unit
N DUNTKG015FM02 R/C OPC Unit
N DUNTKG017FM01 3D-IR Unit
N RUNTKA936WJQZ Wi-Fi UNIT
N RUNTKA934WJQZ POWER UNIT (LC-60LE745/845/847/C7450/C8470)
N RUNTKA935WJQZ POWER/DRIVER UNIT (LC-70LE745/845/847/C7450/C8470)
N RUNTKA944WJZZ S-LED Unit A, x2 (LC-60LE745/C7450)
N RUNTKA966WJZZ S-LED Unit A, x2 (LC-60LE845/847/C8470)
N RUNTKA945WJZZ S-LED Unit B, x2 (LC-60LE745/C7450)
N RUNTKA967WJZZ S-LED Unit B, x2 (LC-60LE845/847/C8470)
N RUNTKA943WJZZ S-LED Unit, x6 (LC-70LE745/C7450)
N RUNTKA965WJZZ S-LED Unit, x6 (LC-70LE845/LE847U/C8470)
No. PARTS CODE DESCRIPTION
N CLCDTA256WE01 60" LCD Panel Module Unit (LC-60LE745/C7450)
N CLCDTA256WE03 60" LCD Panel Module Unit (LC-60LE845/847/C8470)
N CLCDTA255WE01 70" LCD Panel Module Unit (LC-70LE745/C7450/847)
N CLCDTA255WE03 70" LCD Panel Module Unit (LC-70LE845/LE847/C8470)
N R1LK600D3HB70Z 60" Panel Unit (LC-60LE745/C7450) (LK600D3HB70Z)
N R1LK600D3HB80Z 60" Panel Unit (LC-60LE845//847/C8470) (LK600D3HB80Z)
N R1LK695D3GV00E 70" Panel Unit (LC-70LE745/C7450) (LK695D3GV00E)
N R1LK695D3GV00D 70" Panel Unit (LC-70LE845/70LE847/C8470) (LK695D3GV00D)
No. PARTS CODE DESCRIPTION Q'ty
IC2004 RH-iXD241WJNUQ IC (Monitor Microprocessor) 1
No. PARTS CODE DESCRIPTION Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit 2
N QCNW-M580WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LV) 1
N QCNW-M539WJQZ Connecting Cord L=1000mm 24pins, Main to POWER Unit (PD) 1

Sharp LC-60LE745U Specifications

General

Display diagonal	60 \
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Contrast ratio (dynamic)	8000000:1
Viewing angle, horizontal	176 °
3D	Yes
3D type	Active
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Electronic Program Guide (EPG)	-
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	170 W
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	366 mm
Height (with stand)	887 mm
Weight (with stand)	34500 g
Depth (without stand)	55 mm
Width (without stand)	1390 mm
Height (without stand)	838 mm
Weight (without stand)	27500 g
