PARTS GUIDE

Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these

parts with specified ones for maintaining the safety and performance of the set.

This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)

PartsGuide

[1] PRINTED WIRING BOARD

ASSEMBLIES

[2] LCD PANEL MODULE Unit

[3] CABINET PARTS (LC-60LE745U/

845U/847U/C7450U/C8470U)

[4] CABINET PARTS (LC-70KE745U/

845U/847U/C7450U/C8470U)

[5] SUPPLIED ACCESSORIES/

PACKING PARTS (LC-60LE745U/

845U/847U/C7450U/C8470U)

[6] SUPPLIED ACCESSORIES/

PACKING PARTS (LC-70LE745U/

845U/847U/C7450U/C8470U)

[7] SERVICE JIG (USE FOR

SERVICING)

CONTENTS

No. S12V760LE745U

LCD COLOR TELEVISION

LC-60LE745U,C7450U

LC-60LE845U,C8470U

LC-60LE847U

LC-70LE745U,C7450U

LC-70LE845U,C8470U

LC-70LE847U

MODELS
