Sharp LC-60LE745U User Manual

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
6 – 14
No video (4)
PC: No external input video [INPUT-8]
Is INPUT-8 selected on the input select menu screen?
YES
NO
Select INPUT-8 on the input select menu screen for the right input signal.
Is IC2601 (HDMI-SW) accessed by I2C, with PC connected, to read the VGA_SCL/SDA data?
Check the DDC-12C line and its peripheral circuits. (IC2601 and its peripherals).
Are there the video signal inputs at pins (AR24/AT24) (G), (AU24) (B) and (AR25) (R) of IC3301 (CPU)?
Are there the VSYNC/HSYNC signal inputs at pins (AM25) and (AN25) of IC3301?
YES
NO
Check the line between SC510 and IC3301,and their peripheral circuits.
Is the T-CON PWB connected?
VBO_LOCKN pin (40) of SC3801 become Low if there is no problem in the connection.
NO Check the T-CON PWB and harness.
Check IC3301 and SC3801 and their
peripheral circuits in Main PWB.
YES
Are the V-By-One HS signal input to the pin of SC3801?
VBO_CN_TXA+/- (36/37pin), VBO_CN_TXB+/- (32/33pin),
VBO_CN_TXC+/- (28/29pin), VBO_CN_TXD+/- (24/25pin).
NO Check IC3301 and its peripheral circuits.
(IC3501/IC3502/IC3503/IC3504, etc.)
YES
Check the panel module and harness.

Sharp LC-60LE745U Specifications

General

Display diagonal	60 \
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Contrast ratio (dynamic)	8000000:1
Viewing angle, horizontal	176 °
3D	Yes
3D type	Active
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Electronic Program Guide (EPG)	-
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	170 W
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	366 mm
Height (with stand)	887 mm
Weight (with stand)	34500 g
Depth (without stand)	55 mm
Width (without stand)	1390 mm
Height (without stand)	838 mm
Weight (without stand)	27500 g
