Sharp LC-60LE745U - Cabinet Parts List (60 Models)

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[3] CABINET PARTS (LC-60LE745U/845U/847U/C7450U/C8470U)
1 CCABBC053WJ31 N X Rear Cabinet Ass'y
1-1 GCABBC053WJ3A N X Rear Cabinet
1-2 HiNDPE034WJSA X Terminal Ind-b
1-3 HiNDPE573WJSA N X OPE Label
1-4 HiNDPE587WJSA N X TERM IND (Side)
1-5 HiNDPE588WJSA N X TERM IND (Bottom)
2 CANGKD512WJ31 N X Center Angle Ass'y, x2
2-1 LANGKD512WJ3W N X Center Angle
2-2 LHLDWA175WJUZ AC J Wire Holder
2-3 NSFTZA546WJFN N X VESA Boss, x2
3 CCOVAE296WJ31 N X Decoration Cover Ass'y
3-1 GCOVAE296WJ3A N X Decoration Cover
3-2 GCOVAE310WJ3A N X 3D IR Cover
3-3 GCOVAE311WJ3A N X Center I-CON Cover
3-4 HDECQB692WJ3A N X LED Decoration
3-5 LHLDWA151WJKZ AB J Wire Holder
3-6 PSPAHC570WJZZ N X Himeron, x2
3-7 TLABZD154WJZZ N X Lisence Label
4 CCOVAE298WJ31 N X Bottom Cover Ass'y
4-1 GCOVAE298WJ3A N X Bottom Cover
4-2 PSPAHC565WJZZ N X Himeron, x2
5 GCOVAC576WJKZ AC J VESA Cover, x4
6 GCOVAE163WJ3A X AC Cord Cover
7 HDECPA090WJZZ X Decoration Sheet (Side)
8 HDECPA091WJZZ X Decoration Sheet (Bottom)
9 HiNDPE569WJSA N X Model Label (for LC-60LE745)
9 HiNDPE602WJSA X Model Label (for LC-60C7450)
9 HiNDPE577WJSA N X Model Label (for LC-60LE845)
9 HiNDPE600WJSA N X Model Label (for LC-60C8470)
9 HiNDPE598WJSA N X Model Label (for LC-60LE847)
10 HiNDPE571WJZZ N X Energy Label (for LC-60LE745/C7450)
10 HiNDPE579WJZZ N X Energy Label (for LC-60LE845/847/C8470)
11 JBTN-A958WJ3A N X Key Button
12 LANGKD145WJFW N X
Side Terminal Angle
13 LANGKD146WJFW X Terminal Angle Width
14 LANGKD518WJ3W N X Stand Angle, x2
15 LHLDWA175WJUZ AC J Wire Holder, x5
16 LHLDWA176WJUZ AC J Wire Holder
17 LHLDWA303WJKA AE J Cable Clamp
18 LX-BZA202WJF8 AA J Screw, x9
19 LX-BZA207WJF7 AA J Screw, x20
20 LX-BZA474WJF8 N X Screw, x11
21 PSPAKA511WJKZ N X Spacer
22 PSPAZC690WJZZ X Conductr (8*255)
23 PSPAZC691WJZZ AE J Conductr (8*180)
24 PSPAZC805WJKZ N X Cooler (25*25*8)
25 PSPAZC877WJKZ N X Shading Sheet
26 PZETKA665WJKZ N X Power Insulation
!
27 QACCDA084WJPZ X AC Cord
28 QCNW-M534WJZZ N X Connecting Cord (SB)
29 QCNW-M540WJZZ N X Connecting Cord (PD)
30 QCNW-M542WJZZ N X Connecting Cord (SP)
31 QCNW-M543WJZZ N X Connecting Cord (RC)
32 QCNW-M544WJZZ N X Connecting Cord (UB)
33 QCNW-M545WJZZ N X Connecting Cord (LW)
34 QCNW-M553WJQZ N X Connecting Cord (L1)
35 RCORFA061WJZZ AG J Ferrite Cord, x2
36 RSP-ZA572WJZZ N X Speaker Unit (L/R), x2
37 RSP-ZA575WJZZ N X Speaker Unit (Woofer)
39 TLABNB037WJZZ X Back Serial Label
40 TLABNE225WJZZ N X Side Serial Label
41 TLABZD155WJZZ N X POP Label (for LC-60LE745)
41 TLABZD168WJZZ X POP Label (for LC-60C7450)
41 TLABZD162WJZZ N X POP Label (for LC-60LE845)
41 TLABZD166WJZZ N X POP Label (for LC-60LC8470)
42 XBPS830P06WS0 AA J Screw, x44
44 XBPS830P08000 AA J Screw, x6
45 XEBS830P12000 AA J Screw, x8
46 PSPAZC854WJKZ X Cooler (12*15*9) (for LC-60LE845/847/C8470)
