Sharp LC-60LE745U User Manual

LC-60/70LE745U,C7450U,LE845U,C8470U,LE847U (1st Edition)
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[4] CABINET PARTS (LC-70KE745U/845U/847U/C7450U/C8470U)
1 CCABBC054WJ31 N X Rear Cabinet Ass'y
1-1 GCABBC054WJ3A N X Rear Cabinet
1-2 HiNDPE034WJSA X Terminal Indica
1-3 HiNDPE573WJSA N X OPE Label
1-4 HiNDPE587WJSA N X TERM IND (Side)
1-5 HiNDPE588WJSA N X TERM IND (Bottom)
2 CANGKD468WJ31 N X Center Angle Ass'y, x2
2-1 LANGKD468WJ3W N X Center Angle
2-2 LHLDWA151WJKZ AB J Wire Holder
2-3 LHLDWA175WJUZ AC J Wire Holder
2-4 NSFTZA546WJFN X VESA BOSS, x2
2-5 PSPAHC566WJZZ N X Himeron
3 CCOVAE297WJ31 N X Decoration Cover Ass'y
3-1 GCOVAE297WJ3A N X Decoration Cover
3-2 GCOVAE310WJ3A N X 3D IR Cover
3-3 GCOVAE311WJ3A N X Center I-CON Cover
3-4 HDECQB692WJ3A N X LED Decoration
3-5 LHLDWA048WJKZ AB J Wire Holder, x2
3-6 LHLDWA151WJKZ AB J Wire Holder
3-7 TLABZD154WJZZ N X Lisence Label
4 GCOVAC576WJKZ AC J VESA Cover, x4
5 GCOVAE163WJ3A X AC Cord Cover
6 GCOVAE299WJ3A N X Bottom Cover, x2
7 HDECPA090WJZZ X Decoration Sheet (Side)
8 HDECPA091WJZZ X Decoration Sheet (Bottom)
9 HiNDPE570WJSA N X Model Label (for LC-70LE745)
9 HiNDPE601WJSA X Model Label (for LC-70C7450)
9 HiNDPE578WJSA N X Model Label (for LC-70LE845)
9 HiNDPE599WJSA N X Model Label (for LC-C8470)
9 HiNDPE597WJSA N X Model Label (for LC-70LE847)
10 HiNDPE572WJZZ N X Energy Label (Except LC-70LE845)
10 HiNDPE580WJZZ N X Energy Label (for LC-70LE845/LE847)
11 JBTN-A958WJ3A N X Key Button
12 LANGKD145WJFW N X
Side Terminal Angle
13 LANGKD146WJFW X Terminal Angle Width
14 LANGKD518WJ3W N X Stand Angle, x2
15 LHLDWA151WJKZ AB J Wire Holder, x2
16 LHLDWA175WJUZ AC J Wire Holder, x2
17 LHLDWA176WJUZ AC J Wire Holder
18 LHLDWA303WJKA AE J Cable Clamp
19 LX-BZA202WJF8 AA J Screw, x9
20 LX-BZA207WJF7 AA J Screw, x20
21 LX-BZA474WJF8 N X Screw, x11
22 PSPAKA511WJKZ N X Spacer
23 PSPAZC690WJZZ X Conductr (8*255)
24 PSPAZC691WJZZ AE J Conductr (8*180)
25 PSPAZC805WJKZ N X Cooler (25*25*8)
26 PZETKA666WJKZ N X Power Insulation
!
27 QACCDA084WJPZ X AC Cord
28 QCNW-M531WJQZ N X Connecting Cord (L1)
29 QCNW-M533WJZZ N X Connecting Cord (PD)
30 QCNW-M534WJZZ N X Connecting Cord (SB)
31 QCNW-M535WJZZ N X Connecting Cord (SP)
32 QCNW-M536WJZZ N X Connecting Cord (RC)
33 QCNW-M537WJZZ N X Connecting Cord (UB)
34 QCNW-M538WJZZ N X Connecting Cord (LW)
35 RCORFA061WJZZ AG J Ferrite Core, x2
36 RSP-ZA572WJZZ N X Speaker Unit (L/R), x2
37 RSP-ZA575WJZZ N X Speaker Unit (Woofer)
38 TLABNB037WJZZ X Back Serial Label
39 TLABNE225WJZZ N X Side Serial Label
40 TLABZD155WJZZ N X POP Label (for LC-70LE745)
40 TLABZD168WJZZ N X POP Label (for LC-70C7450)
40 TLABZD162WJZZ N X POP Label (for LC-70LE845)
40 TLABZD166WJZZ N X POP Label (for LC-70C8470)
40 TLABZD164WJZZ N X POP Label (for LC-70LE847)
41 XBPS830P06WS0 AA J Screw, x50
42 XBPS830P08000 AA N J Screw., x8
43 XEBS830P12000 AA J Screw, x10
46 PSPAZC854WJKZ X Cooler (12*15*9) (for LC-70LE845/847/C8470)

Sharp LC-60LE745U Specifications

General

Display diagonal	60 \
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Contrast ratio (dynamic)	8000000:1
Viewing angle, horizontal	176 °
3D	Yes
3D type	Active
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI port	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
Electronic Program Guide (EPG)	-
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (max)	170 W
Power consumption (standby)	- W

Weight and Dimensions

Depth (with stand)	366 mm
Height (with stand)	887 mm
Weight (with stand)	34500 g
Depth (without stand)	55 mm
Width (without stand)	1390 mm
Height (without stand)	838 mm
Weight (without stand)	27500 g
