Sharp LC-60LE757U Service Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
18
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
C6256 VCKYCY1EB104KY AB J 0.10 25V Ceramic
C6257 RC-AZA074WJZZY AE J Capacitor
C6258 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6259 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6269 VCKYCY1EB104KY AB J 0.10 25V Ceramic
C6271 RC-KZA621WJQZY AA J Capacitor
C6276 VCKYCY1EB104KY AB J 0.10 25V Ceramic
C6280 RC-KZA510WJPZY AB J Capacitor
C6281 RC-KZA510WJPZY AB J Capacitor
C6282 RC-KZA510WJPZY AB J Capacitor
C6288 RC-KZA510WJPZY AB J Capacitor
C6293 RC-KZA510WJPZY AB J Capacitor
C6326 RC-KZA832WJZZY AB J Capacitor
C6327 RC-KZA832WJZZY AB J Capacitor
C6802 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6803 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6804 RC-KZA510WJPZY AB J Capacitor
C6805 RC-KZA510WJPZY AB J Capacitor
C6806 RC-KZA805WJQZY AB J Capacitor
C6807 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6808 RC-KZA510WJPZY AB J Capacitor
C6809 VCKYTV1CB105KY AC J 1.0 16V Ceramic
C6810 RC-KZA510WJPZY AB J Capacitor
C6811 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6812 RC-KZA110WJZZY AD J Capacitor
C6813 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6815 RC-KZA110WJZZY AD J Capacitor
C6816 RC-KZA805WJQZY AB J Capacitor
C6818 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6819 RC-KZA110WJZZY AD J Capacitor
C6820 RC-KZA110WJZZY AD J Capacitor
C6821 RC-KZA110WJZZY AD J Capacitor
C6822 RC-KZA110WJZZY AD J Capacitor
C6823 RC-KZA510WJPZY AB J
Capacitor
C6824 R
C-KZA510WJPZY AB J Capacitor
C6831 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6832 VCKYCZ1EB104KY AA J 0.10 25V Ceramic
C6833 RC-KZA510WJPZY AB J Capacitor
C6835 RC-KZA510WJPZY AB J Capacitor
C6839 RC-KZA510WJPZY AB J Capacitor
C6842 RC-KZA510WJPZY AB J Capacitor
C6844 RC-KZA510WJPZY AB J Capacitor
C6851 RC-KZA848WJZZY AB J Capacitor
C6852 RC-KZA848WJZZY AB J Capacitor
C6853 RC-KZA848WJZZY AB J Capacitor
D6203 VHDRB520S30-1Y AC J RB520S-30TE61
D6205 VHDRB055L30-1Y AC J RB055L-30TE25
D6206 RH-EXA613WJZZY AD J KDZTR16B
D6207 VHDRB552EA+-1Y AC J RB552EATR
D6208 VHDRB552EA+-1Y AC J RB552EATR
D6210 VHDRB552EA+-1Y AC J RB552EATR
D6211 VHDRB055L30-1Y AC J RB055L-30TE25
FB4801 RBLN-A561WJQZY AA X Balun
FB4901 RBLN-A193WJZZY AB J Balun
FB4902 RBLN-A193WJZZY AB J Balun
FB4903 RBLN-A193WJZZY AB J Balun
FB4904 RBLN-A193WJZZY AB J Balun
FB4905 RBLN-A193WJZZY AB J Balun
FB4906 RBLN-A193WJZZY AB J Balun
FB5101 RBLN-A206WJZZY AA J Balun
FB5801 RBLN-A206WJZZY AA J Balun
FB5803 RBLN-A206WJZZY AA J Balun
FB5804 RBLN-A206WJZZY AA J Balun
FB5805 RBLN-A379WJQZY AA J Balun
FB5806 RBLN-A379WJQZY AA J Balun
FB5807 RBLN-A379WJQZY AA J Balun
FB5808 RBLN-A379WJQZY AA J Balun
FB5809 RBLN-A379WJQZY AA J Balu
n
FB5810 RBLN-A379WJQZY AA J Balun
FB5811 RBLN-A379WJQZY AA J Balun
FB5812 RBLN-A379WJQZY AA J Balun
FL5101 RFiLZA031WJQZY AE J Filter
IC4902 VHiTHCV216+-1Q AQ J THCV216
IC4903 VHiTHCV216+-1Q AQ J THCV216
IC4904 VHiLVC1G02W-1Y AB N J 74LVC1G02GW,125
IC5101 VHiTC7WU04K-1Y AC N J TC7WU04FK(T5L,F,T)
IC5103 RH-iXD458WJQZQ AS J LCMXO2-1200HC-4TG100C
IC5801 RH-iXD089WJQZQ BG J UPD811308F1-611-KNB-A
IC5803 Not Available - -
W25Q80BVSNIG (Please replace the LCD CONTROL PWB when it is necessary to
replace this IC.)
IC5804 VHiBU4229G+-1Y AC J BU4229G-TR
IC6201 VHiBD81000+-1Y AL J BD81000MUV-E2
IC6202 VHiBU4229G+-1Y AC J BU4229G-TR
IC6203 VHiSTVM100D-1Y AC X STVM100DC6F
IC6204 VHiPQ200WNA-1Y AG J PQ200WNA1ZPH
[3] DUNTKF975FM20 (LCD CONTROL Unit)
