Sharp LC-60LE757U Service Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
22
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R6338 VRS-CZ1JF1R0JY AA J 1.0 1/16W Metal Oxide
R6339 VRS-CZ1JF1R0JY AA J 1.0 1/16W Metal Oxide
R6343 VRS-CZ1JF1R0JY AA J 1.0 1/16W Metal Oxide
R6344 VRS-CZ1JF1R0JY AA J 1.0 1/16W Metal Oxide
R6362 VRK-SB1FF100JY AA J 10 1/32W Metal Composition
R6363 VRK-SB1FF100JY AA J 10 1/32W Metal Composition
R6803 VRS-CY1JF000JY AA J 0 1/16W Metal Oxide
R6804 VRS-CY1JF000JY AA J 0 1/16W Metal Oxide
R6814 VRS-CZ1JF103JY AA J 10k 1/16W Metal Oxide
R6818 VRS-CY1JF000JY AA J 0 1/16W Metal Oxide
R6819 VRS-CY1JF000JY AA J 0 1/16W Metal Oxide
R6824 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6825 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6826 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6838 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R6841 VRS-CZ1JF473JY AA J 47k 1/16W Metal Oxide
R6845 VRS-TW2HF000JY AA J 0 1/2W Metal Oxide
R6846 VRS-TW2HF3R3JY AA J 3.3 1/2W Metal Oxide
R6847 VRS-TW2HF3R3JY AA J 3.3 1/2W Metal Oxide
R6848 VRS-TW2HF000JY AA J 0 1/2W Metal Oxide
R6854 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6855 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6856 VRS-CB1JF000JY AC J 0 1/16W Metal Oxide
R6860 VRK-SB1FF100JY AA J 10 1/32W Metal Composition
R6861 VRK-SB1FF100JY AA J 10 1/32W Metal Composition
R6862 VRK-SB1FF100JY AA J 10 1/32W Metal Composition
SC4801 QCNCWA671WJQZY AH J Connector
SC5301 QCNCWA801WJZZY AG J Connector
SC5302 QCNCWA801WJZZY AG J Connector
X5801 RCRSCA237WJQZY AD J Crystal
[4] DUNTKF961FM19/20 (LCD CONTROL Unit)
C4801 VCKYCZ1EB104KY AA J 0.1 25V Ceramic
C4823 RC-AZA074WJZZY AE J Capacitor
C4824 VCKYCY1EB104KY AB J 0.1 25V Ceramic
C4825 VCKYCY1EB104KY AB J 0.1 25V Ceramic
C4901 RC-KZA176WJZZY AC J Capacitor
C4902 RC-KZA176WJZZY AC J Capacitor
C4907 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4908 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4909 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4910 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4911 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4912 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4913 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4914 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C4915 RC-KZA116WJZZY AC J Capacitor
C4916 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4917 RC-KZA116WJZZY AC J Capacitor
C4918 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4919 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4921 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4923 RC-KZA116WJZZY AC J Capacitor
C4924 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4925 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4926 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4927 RC-KZA116WJZZY AC J Capacitor
C4928 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4929 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4930 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4931 RC-KZA116WJZZY AC J Capacitor
C4932 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4933 RC-KZA116WJZZY AC J Capacitor
C4934 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4936 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4938 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4939 R
C-KZA116WJZZY AC J Capacitor
C4940 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4941 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4942 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4943 RC-KZA116WJZZY AC J Capacitor
C4944 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4945 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C4946 VCKYCZ1EB103KY AA J 0.01 25V Ceramic
C5801 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C5802 VCKYCY1EB103KY AA J 0.01 25V Ceramic
C5803 VCCCCZ1HH8R0DY AA J 80p 50V Ceramic
C5804 VCCCCZ1HH100DY AB J 10p 50V Ceramic
C5805 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C5806 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C5807 RC-KZA116WJZZY AC J Capacitor
C5808 RC-KZA116WJZZY AC J Capacitor
C5809 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C5810 VCKYCZ1AB104KY AB J 0.1 10V Ceramic
C5811 RC-KZA116WJZZY AC J Capacitor
[3] DUNTKF975FM20 (LCD CONTROL Unit)
