Sharp LC-60UI9362K - How to Connect Your Set

43
43
Note: Tablets and/or phones can be charged via the USB port, however, it’s not possible to play back
media from these devices.
Note: Some USB devices may need to be connected to an external power supply before being used with
this input, i.e. powered hard drive.
How to Connect Your Set
Connecting to a USB device
To use the USB input, TV source should be set to USB Media.
Connecting the TV to Earphones
When connecting via the TV’s 3.5mm earphone output, this will disable the TV speakers.
3.5mm
earphone
CONNECTIONS
USB
USB
USB
Mini
OPTION 1 Connection to a USB memory stick.
OPTION 2 Connection to an external hard drive.
HDD
