LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
v
• LC-60/70UQ17U
NOTE: *1 Replace MAIN PWB Units (DKEYMG381FM01) in case of IC3103 failure.
Replace MAIN PWB Units (DKEYMG382FM01) in case of IC3103, IC3301 failure.
*2 Replace LCD CONTROL Units (DUNTKG400FM**) in case of IC5803 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM10 LCD CONTROL (T-CON) Unit (LC-60UQ17U)
N DUNTKG400FM11 LCD CONTROL (T-CON) Unit (LC-70UQ17U)
N DUNTKF800FM54 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJN1 WiFi+BT Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60UQ17U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70UQ17U)
N RUNTKB075WJZZ LED Unit (LC-60UQ17U)
N RUNTKB077WJZZ LED Unit (LC-70UQ17U)
Ref No. Parts No. Description Q’ty
IC2004 RH-iXD515WJNSQ IC (Monitor Microprocessor) 1
IC2503 RH-iXD741WJZZS IC (Flash for HDMI receiver) (DKEYMG382FM01) 1
NO. PARTS CODE DESCRIPTION
SERVICE JIG (USE FOR SERVICING) (LC-60/70EQ10U/SQ10U,15U,17U)
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2 (LC-60/70EQ10U)
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit (PL)
SERVICE JIG (USE FOR SERVICING) (LC-60/70TQ15U/UQ17U,80UQ17U)
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-N560WJQZ Connecting Cord L=650mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit (PL)
