LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
iv
LC-60EQ10U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
• LC-60/70EQ10U
• LC-60/70SQ10U
• LC-60/70SQ15U
• LC-60/70SQ17U
• LC-60/70TQ15U
NO. PARTS CODE DESCRIPTION
N DKEYMG381FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60EQ10U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70EQ10U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM02 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60EQ10U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70EQ10U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ10U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ10U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM02 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ10U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ10U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ15U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ15U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ15U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ15U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ17U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ17U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ17U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ17U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM10 LCD CONTROL (T-CON) Unit (LC-60TQ15U)
N DUNTKG400FM11 LCD CONTROL (T-CON) Unit (LC-70TQ15U)
N DUNTKF800FM54 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJN1 WiFi+BT Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60TQ15U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70TQ15U)
N RUNTKB075WJZZ LED Unit (LC-60TQ15U)
N RUNTKB077WJZZ LED Unit (LC-70TQ15U)
To Next Page
