Sharp LC-70LE732U - Outline

LC-60LE630U/U(A),6300U/U(A)/U(B),LC-70LE735U
i
LC60LE630U
Service Manual
OUTLINE, MODIFIED PARTS AND MAJOR SERVICE PARTS
OUTLINE
This model is based on the LC-60LE632U/LC-70LE732U and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-60LE632U/LC-70LE732U (S31O870LE732U) Service Man-
ual.
The following model label corresponds to this service manual.
(LC-60LE630U(A),6300U(A))
(LC-60LE6300U(B))
The new model can be identified with the following markings.
• As to the new service Parts, the mark A is printed on the model label.
LC-60LE630U
LC-60LE630U
The new model can be identified with the following markings.
• As to the new service Parts, the mark B is printed on the model label.
LC-60LE630U
LC-60LE630U
B
B
B
B
