[10] REMOVING OF MAJOR PARTS (LC-80LE757U/LE857U)
1. Removing of Stand Unit and Rear Cabinet Ass'y.
1. Remove the 2 lock screw and detach the Stand Cover. (LC-80LE757U/LE857U)
2. Remove the 4 lock screws and detach the Stand Unit.
3. Disconnect AC Wire and detach the AC Cord .
4. Remove the 37 lock screws , 5 lock screws , 5 lock screws and detach the Rear Cabinet Ass'y (L) and detach the Rear Cabinet Ass'y
(R) .
