[11] The location putting on the heat measure sheet (LC-80LE650U/657U/757U/857U/
C6500U)
1. MAIN PWB Unit
• LC-80LE650U/657U/C6500U
• LC-80LE757U/857U
2. LCD CONTROL PWB Unit
• LC-80LE757U/857U
(3) Stick *****
PSPAZC805WJKZ
MAIN-CPU COOL(B)
(4) Stick *****
PSPAZC854WJKZ
MAIN-CPU COOL
Base line
Punch mark
(1) Stick* **
PSPAZD031WJKZ
COOLER:20X20X7t
Base line
carved line
Base line
carved line
(1) Stick***
PSPAZD031WJKZ
COOLER:20X20X7t
