OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Units (DKEYMF953FM06) in case of IC3103 and IC3104 failure.
*2 Replace LCD CONTROL Units (DUNTKF975FM20) in case of IC5803 failure.(LC-60/70LE650U/C6500U/LE657U)
OTHER Unit
IC For Exclusive Use Of The Service
Ref NO. PARTS CODE DESCRIPTION
LC-60/70LE650U/C6500U/LE657U
N DKEYMF953FM06 MAIN Unit
N DUNTKF975FM20 LCD CONTROL Unit
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit (LC-60/70LE657U)
N DUNTKG014FM03 ICON Unit (LC-60/70LE650U/C6500U)
N DUNTKG015FM03 R/C OPC Unit
N RUNTKA936WJQZ Wi-Fi Unit
N RUNTKB126WJQZ BLUETOOTH Unit (LC-60/70LE657U)
N RUNTKB109WJQZ POWER/LED DRIVER Unit (LC-60LE650U/C6500U/LE657U)
N RUNTKB131WJQZ POWER/LED DRIVER Unit (LC-70LE650U/C6500U/LE657U)
LC-60/70LE755U/757U/857U/C7500U
N DKEYMF953FM06 MAIN Unit
N DUNTKF961FM19 LCD CONTROL UNIT (LC-60LE755U/757U/857U/C7500U)
N DUNTKF961FM20 LCD CONTROL UNIT (LC-70LE755U/757U/857U/C7500U)
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit (LC-60/70LE755U/757U/857U)
N DUNTKG014FM03 ICON Unit (LC-60/70C7500U)
N DUNTKG015FM03 R/C OPC Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60LE755U/757U/857U/C7500U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70LE755U/757U/857U/C7500U)
N RUNTKA936WJQZ WiFi Unit
N RUNTKB126WJQZ BLUETOOTH Unit (LC-60/70LE755U/757U/857U)
LC-80LE650U,LE657U,C6500U,LE757U,LE857U
N DKEYMF953FM06 MAIN Unit
N DUNTKG281FM01 LCD CONTROL Unit (LC-80LE650U/LE657U/C6500U)
N DUNTKF961FM21 LCD CONTROL Unit (LC-80LE757U/LE857U)
N DUNTKF800FM53 KEY Unit
N DUNTKG014FM02 ICON Unit (LC-80LE757U/LE857U/LE657U)
N DUNTKG014FM03 ICON Unit (LC-80LE650U/C6500U)
N DUNTKG015FM03 R/C OPC Unit
N RUNTKA936WJQZ WiFi Unit
N RUNTKB126WJQZ BLUETOOTH UNIT (LC-80LE657U/LE757U/LE857U)
N RUNTKB090WJQZ POWER Unit (LC-80LE650U/LE657U/C6500U)
N RUNTKB133WJQZ POWER/DRIVE Unit (LC-80LE757U)
N RUNTKB120WJQZ POWER/DRIVE Unit (LC-80LE857U)
Ref NO. PARTS CODE DESCRIPTION
N R1JE600D3GV2AZ 60" LCD PANEL MODULE Unit (JE600D3GV2AZ) (LC-60LE650U/C6500U/LE657U)
N R1JE695D3GW8CD 70" LCD PANEL MODULE Unit (JE695D3GW8CD) (LC-70LE650U/C6500U/LE657U)
N R1JE600D3HD60Z 60" LCD PANEL Unit (JE600D3HD60Z) (LC-60LE755U/757U/857U/C7500U)
N R1JE695D3HB10V 70" LCD PANEL Unit (JE695D3HB10V) (LC-70LE755U/757U/857U/C7500U)
N R1JE800D3GW50M 80" LCD PANEL MODULE Unit (JE800D3GW50M) (LC-80C6500U/LE657U/LE650U)
N R1LK800D3HA80R 80" LCD PANEL Unit (LK800D3HA80R) (LC-80LE757U/857U)
Ref No. Parts No. Description Q’ty
IC2004 RH-iXD515WJN7Q IC (Monitor Microprocessor) 1
