Enjoying 3D Image Viewing (For the UQ17U, TQ15U, SQ17U, SQ15U and LE657U models)
ENG 5-2
Preparing for the 3D glasses
Supplied accessories (For the UQ17U, SQ17U and
LE657U models)
Make sure the following accessories are provided with
the 3D glasses.
3D glasses x 2 Cleaning cloth x 1
NOTE
The illustrations above are for explanation purposes and
may vary slightly from the actual accessories.
Part Names
1 Power button
2 LED indicator
NOTE
The power turns off automatically in the following cases:
When pairing fails
When the 3D glasses are not operated in standby for
15 seconds
When the power button is pressed for 2 or more seconds
with the power off, pairing with the TV starts.
When the power button is pressed for 2 or more seconds
with the power on, the power turns off.
When paired, the power will turn off if the power button is
pressed for 2 or more seconds.
When the power button is pressed for less than 2
seconds with the power off, the 3D glasses will turn to
standby.
When the 3D glasses are in 3D mode with the power on,
pressing the power button for less than 2 seconds will
turn the 3D glasses to 2D mode.
When the 3D glasses are in 2D mode with the power on,
pressing the power button for less than two seconds will
turn the 3D glasses to 3D mode.
When paired, the 3D glasses will be non-reactive if the
power button is pressed for less than 2 seconds.
2 LED light
When paired with the TV, the LED light blinks in red and
green.
When pairing is completed successfully, the LED blinks in
green for 3 seconds.
When the power is turned on, the LED lights up in green
for 3 seconds.
When in 3D mode, the LED blinks in green in 3-second
intervals.
When in 2D mode, the LED blinks in red in 3-second
intervals.
When the power is turned off, the LED blinks in green 3
times.
NOTE
When in low voltage mode:
When in 3D mode, the LED blinks in green in 3-
second intervals.
When in 2D mode, the LED blinks in red in 3-second
intervals.
