Sharp MD-MT866H Service Manual

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT866H/MD-MT866W
– 1 –
INTEGRATED CIRCUITS
IC101 VHIIR3R58M/-1 J AM RF Signal Processor,IR3R58M
IC200 VHI62GR2522-1 J AG 2.5V Regulator,62GR2522
IC201 VHILR37815+-1 J BF Endec/Servo/Atrac,LR37815
IC202 RH-IX2824AFZZ J AX 16MBit D-RAM,IX2824AF
IC251 VHIS80808LN-1 J AE Reset,S80808LN
IC271 VHI75S54FU+-1 J AG OP AMP,75S54FU
IC351 VHI74ACT02T-1 J AE Head Driver,74ACT02T
IC353 VHIFTD2005/-1 J AG Head Driver,FTD2005
IC354 VHICPH5608/-1 J AH Head Driver,CPH5608
IC401 RH-IX0357AWZZ J BA System Microcomputer,
IX0357AW
IC402 VHI58X2404T-1 J AF EEPROM,58X2404T
IC404 VHIN7SZ86P5-1 J AE Gate IC,N7SZ86P5
IC431 VHIS80820LN-1 J AD Reset,S80820LN
IC501 VHIAK4551VT-1 J AU AD/DA Converter,AK4551VT
IC601 VHIBD6606KV-1 J BB Motor Drive,BD6606KV
IC651 VHILB1938T+-1 J AL Motor Drive,LB1938T
IC701 VHIIR3R54N/-1 J AQ Audio Amp.,IR3R54N
IC703 VHIIR3R59N/-1 J AN Audio Amp.,IR3R59N
IC771 VHI62GR2322-1 J AF 2.3V Regulator,62GR2322
IC801 VHIS80814LN-1 J AE Reset,S80814LN
IC821 VHICPH3403/-1 J AE N-ch MOS FET,CPH3403
IC822 VHIIR3M14N/-1 J AK DC/DC Converter,IR3M14N
IC841 VHI6372C281-1 J AH 2.8V UP Converter,6372C281
IC842 VHIXC62HS02-1 J AE Power Supply Microcomputer,
XC62HS02
IC851 VHICPH3403/-1 J AE N-ch MOS FET,CPH3403
IC852 VHIIR3M14N/-1 J AK DC/DC Converter,IR3M14N
IC871 VHITC7S86FU-1 J AE Exclusive or Gate,TC7S86FU
IC873 VHI62GR4522-1 J AG 4.5V Regulator,62GR4522
TRANSISTORS
Q103 VHIFDG312P/-1 J AD P-ch Power MOS,FDG312 P
Q251 VS2SA17457/-1 J AB Silicon,PNP,2SA17457
Q252 VSFTD2017++-1 J AC N-ch MOS FET,FTD2017
Q253 VHIRN4904//-1 J AD Power Select Charge Drive,
RN4904
Q254 VS2SA1832GR-1 J AC Silicon,PNP,2SA1832 GR
Q261 VHIHN1C01FU-1 J AD Power Transistor,HN1C01 FU
Q493 VS2SA1832GR-1 J AC Silicon,PNP,2SA1832 GR
Q711 VSRN1444A//-1 J AC Digital,NPN,RN1444 A
Q721 VS2SD1979S+-1 J AC Silicon,NPN,2SD1979 S
Q801 VHIRN4904//-1 J AD Power Select Charge Drive,
RN4904
Q802 VSFDN339N++-1 J AG N-ch MOS FET,FDN339 N
Q803 VS2SA17457/-1 J AB Silicon,PNP,2SA17457
Q804 VHIHN1C01FU-1 J AD Power Transistor,HN1C01 FU
Q805 VS2SA1832GR-1 J AC Silicon,PNP,2SA1832 GR
Q806,807 VHIHN1C01FU-1 J AD Power Transistor,HN1C01 FU
Q821 VHIHN1C01FU-1 J AD Power Transistor,HN1C01 FU
Q825 VSDTC144EE/-1 J AB Digital,NPN,DTC144 EE
Q901 VSRN1104///-1 J AB Digital,NPN,RN1104
QA01 VSUN5210+++-1 J AC Digital,NPN,UN5210
DIODES
D351 VHDSBE803//-1 J AD Silicon,SBE803
D431 VHD1SS361//-1 J AB Silicon,1SS361
D461 VHDRB731U//-1 J AC Silicon,RB731U
D462 VHDRB521S30-1 J AC Silicon,RB521S30
D491 VHE015Z5R1Y-1 J AD Zener,5.1V,015Z5.1Y
D492 VHE15AZ7R5Y-1 J AC Zener,7.5V,15AZ7.5Y
D493 VHE015Z5R1Y-1 J AD Zener,5.1V,015Z5.1Y
D494 VHE15AZ7R5Y-1 J AC Zener,7.5V,15AZ7.5Y
D495,496 VHEMA8075M/-1 J AC Zener,MA8075M
D651 VHDF10J2E//-1 J AC Silicon,F10J2E
D771,772 VHDF10J2E//-1 J AC Silicon,F10J2E
D801 VHDRB521S30-1 J AC Silicon,RB521S30
D821 VHDD1FH3+++-1 J AE Schottky,D1FH3
D822 VHDHRB0103B-1 J AC Silicon,HRB0103B
D831,832 VHDHRB0103B-1 J AC Silicon,HRB0103B
D841 VHDF10J2E//-1 J AC Silicon,F10J2E
D842 VHDHRB0103B-1 J AC Silicon,HRB0103B
D851,852 VHDF10J2E//-1 J AC Silicon,F10J2E
D861,862 VHDF10J2E//-1 J AC Silicon,F10J2E
LEDA01 VHPCL190HBX-1 J AR LED,CL190HBX
COILS
L100 VPBNN100K0000 J AC 10 µH
L171 RCILC0356AFZZ J AC 10 µH
L202 VPBNN100K0000 J AC 10 µH
L204 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L452 RCILC0352AFZZ J AB Tip Impeder,150mA
L453,454 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L456~458 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L491 VRS-TV2AB330J J AA 33 ohms,1/10W
L601,602 RCILC0372AFZZ J AC 22 µH,Choke
L603 RCILC0358AFZZ J AC 4.7 µH,Choke
L604 RCILC0372AFZZ J AC 22 µH,Choke
L608 RCILC0372AFZZ J AC 22 µH,Choke
L609 RCILC0356AFZZ J AC 10 µH
L702,703 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L704 RCILC0352AFZZ J AB Tip Impeder,150mA
L711 RCILC0352AFZZ J AB Tip Impeder,150mA
L712~714 RCILC0353AFZZ J AB Tip Solid Induction,100mA
L821 RCILC0005AWZZ J AF 10 µH,Choke
L841 RCILC0358AFZZ J AC 4.7 µH,Choke
L851 RCILC0005AWZZ J AF 10 µH,Choke
VIBRATORS
XL201 RCRSC0028AFZZ J AH Crystal,33.868 MHz
XL401 RCRM-0203AFZZ J AD Ceramic,4.19 MHz
CAPACITORS
C100 VCSATN0JJ106M J AC 10 µF,6.3V,Electrolytic,Tantalum
C102,103 VCKYCY0JB105K J AC 1 µF,6.3V
C106 VCKYCY0JB105K J AC 1 µF,6.3V
C107 VCKYCZ1AB104K J AB 0.1 µF,10V
C108,109 VCKYCY0JB105K J AC 1 µF,6.3V
C110 VCKYCY1AB224K J AB 0.22 µF,10V
C111 VCKYCY0JB105K J AC 1 µF,6.3V
C112 VCKYCZ1AB104K J AB 0.1 µF,10V
C113 VCKYCY0JB105K J AC 1 µF,6.3V
C114 VCCCCZ1HH5R0C J 5 pF (CH),50V
C121,122 VCKYCZ1HB221K J 220 pF,50V
C123,124 VCKYCZ1HB331K J 330 pF,50V
C130,131 VCKYCZ1AB104K J AB 0.1 µF,10V
C132,133 VCKYCY1AB224K J AB 0.22 µF,10V
C151 VCKYCZ1CB103K J AB 0.01 µF,16V
C165 VCKYCZ1AB333K J AB 0.033 µF,10V
C171,172 RC-SZ0002AWZZ J AD 33 µF,6.3V,Electrolytic
C200 VCKYCY0JB105K J AC 1 µF,6.3V
C201 VCSAPR0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C202 VCSATK0JJ476M J AD 47 µF,6.3V,Electrolytic,Tantalum
C203 VCKYCZ1AB104K J AB 0.1 µF,10V
C204 VCKYCY1AB474K J AC 0.47 µF,10V
C205 VCKYCZ1AB104K J AB 0.1 µF,10V
C207 VCKYCZ1AB104K J AB 0.1 µF,10V
C209,210 VCKYCZ1AB104K J AB 0.1 µF,10V
C211 VCCCCZ1HH5R0C J 5 pF (CH),50V
C212 VCCCCZ1HH8R0D J 8 pF (CH),50V
C251,252 VCKYCZ1AB104K J AB 0.1 µF,10V
C253 VCKYCZ1CB103K J AB 0.01 µF,16V
C271~274 VCKYCZ1AB104K J AB 0.1 µF,10V
C291 VCKYCZ1AB104K J AB 0.1 µF,10V
C292 VCKYCZ1CB103K J AB 0.01 µF,16V
C351 VCCCCY1HH470J J AA 47 pF (CH),50V
C353 VCSAPR0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C354 VCKYCZ1AB104K J AB 0.1 µF,10V
C357 VCKYCZ1AB104K J AB 0.1 µF,10V
C361 VCKYTV1HB393K J AB 0.039 µF,50V
C401 VCKYCZ1AB104K J AB 0.1 µF,10V
C431 VCKYCY1AB474K J AC 0.47 µF,10V
C451 VCKYCY1EB223K J AB 0.022 µF,25V
C454 VCKYCZ1HB222K J 0.0022 µF,50V
C491 VCKYTV1CB104K J AA 0.1 µF,16V
C492 VCKYCY0JB105K J AC 1 µF,6.3V
C493 VCKYCY1AB474K J AC 0.47 µF,10V
C500 VCSAPR0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C501,502 VCKYCZ1HB222K J 0.0022 µF,50V
C503 VCSAPR1AJ335M J AD 3.3 µF,10V,Electrolytic,Tantalum
C505,506 VCKYCZ1HB102K J 0.001 µF,50V
C509,510 VCKYCY0JB105K J AC 1 µF,6.3V
C511 VCKYCZ1AB104K J AB 0.1 µF,10V
C600 RC-SZ0001AWZZ J AG 22 µF,6.3V,Electrolytic
C601~604 VCKYCY0JB105K J AC 1 µF,6.3V

Sharp MD-MT866H Specifications

General

Brand	Sharp
Model	MD-MT866H
Category	Minidisc Recorder
Language	English
