Sharp MD-MT866H Service Manual

MD-MT866H/MD-MT866W
PACKING METHOD (MD-MT866H(S) FOR U.K. ONLY)
Setting position of switches and knobs
Remote Control HOLD CANCEL
13
19
3
1
2
5
23
20
18
4
9
24
16
22
OPENOPEN
OPENOPEN
15
21
7
14
10
17
6
1 GCASZ0002AWSA Battery Case
2 RADPA8046AWZZ AC Adapter
3 RPHoH0176AFSA Headphonese
4 RRMCW0007AWSA Remote Control
5 SPAKC1103AWZZ Packing Case
6 QCNWG0422AFZZ Connecting Cord, Optical Type
7 SPAKA0284AWZZ Packing
9 TCADS0003AWZZ Service Card
10 TCAUH0066AWZZ Caution
13 TiNSE0334AWZZ Operation Manual
14 TiNSE0336AWZZ Quick Guide
15 SPAKZ0699AWZZ AC Adapter Pad
16 TLABZ0695AWZZ Label, Caution
17 TCAUH0072AWZZ Sheet, Caution
18 UBAGC0005AWZZ Battery Carrying Case
19 UBAGC0006AWSA Carrying Case
20 UBATM0006AWZZ Battery
21 SPAKZ0692AWZZ Sheet, Bubble
22 RUNTZ0028AWM1 Charging Stand
23 QCNWG0382AFZZ Connecting Cord, RCA Type
24 SPAKZ0490AWZZ Spacer
