PRINT IMAGE POSITION & MAGNIFICATION
Automatic Adjustment:-
Sim 50-28 BK MAG ADJ (Main Scan Mag).
SETUP/PRINT ADJ (Lead, Offset or All).
Manual Adjustment:-
Sim 50-10 BK MAG (inside dimension) to 240mm.
Sim 50-10 Image Off Centre Adjustment.
Sim 50-05 Printer Lead Edge & Void Adjust.
IMAGE SKEW & COLOUR REGISTRATION
Sim 61-04 Image Skew Adjustment (Black) Select A3 Paper.
Sim 50-22 Colour Registration/Skew & OPC Drum Phase Adjustment
Check/Adjust SKEW (CMY) so value is Close to 0 as possible
(Result=OK).
HALF TONE COLOUR CALIBRATION
Sim 46-74 Engine & Printer Colour Calibration Select FACTORY Mode.
COPY IMAGE QUALITY
Check Image Quality (Copy Mode) – Density, Magnification, Lead Edge & Void.
If NG, perform the following adjustments as required:-
Sim 46-01 Copy Density Adjust. (Colour).
Sim 46-02 Copy Density Adjust. (B/W).
Sim 46-09 SPF Copy Density Adjust.
Sim 50-28 OC ADJUST (Lead, Offset & Mag).
SPF ADJ:(Lead, Offset & Sub scan).
Manual Adjustment (Magnification, Lead Edge, Void, Off Centre etc).:
Sim 48-01 Magnification Adjustment (OC & SPF).
Sim 50-01 Lead/Rear Edge, Loss & Void Adjust.
Sim 50-12 OC & SPF Off Centre Adjust.
PRINT IMAGE QUALITY
Check Image Quality (Print Mode) – Density.
Sim 64-05 PCL Density Test Page
Sim 64-06 PS Density Test Page [MX-PK11].
