Sharp MX-C250 Service Manual

MX-C250 SIMULATION 6 – 30
43-24
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the correction of the tempera-
ture adjustment value of SIM 43-1 and 43-
4.
Section
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1C Change
*About the correction value
Each correction value for temperature: 1count = 1Degree C
Each paper exit count: 1count = 1pcs paper
Each cool down time: 1count = 1sec
<Code descriptions>
Correction value -49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
Item/Display Content
Setting
range
Grou
p A
Grou
p B
Grou
p C
Acc. Desti-
nation set-
ting(O/X)
1 NN_120_FUS_DUP_HL_UM
Correction amount for normal paper in duplex printing under 120
degrees C in N/N-Warm Up
1 - 99 50 50 50
X
2 LL_120_FUS_DUP_HL_UM
Correction amount for normal paper in duplex printing under 120
degrees C in L/L-Warm Up
1 - 99 50 50 50
X
3 HH_120_FUS_DUP_HL_UM
Correction amount for normal paper in duplex printing under 120
degrees C in H/H-Warm Up
1 - 99 50 50 50
X
4 NN_120_FUS_DUP_CNT
Number of sheets of application of normal paper in duplex printing
under 120 degrees C in N/N-Warm Up (Setting of the number of
sheets at which application is started)
1 - 60555
X
5 LL_120_FUS_DUP_CNT
Number of sheets of application of normal paper in duplex printing
under 120 degrees C in L/L-Warm Up (Setting of the number of
sheets at which application is started)
1 - 60 10 10 10
X
6 HH_120_FUS_DUP_CNT
Number of sheets of application of normal paper in duplex printing
under 120 degrees C in H/H-Warm Up (Setting of the number of
sheets at which application is started)
1 - 60555
X
7 COOL_DOWN_HEAVY
Cool-down time heavy paper (Time (sec) required to return to the
plain paper fusing temperature)
1 - 60555
X
8 COOL_DOWN_OHP
Cool-down time OHP (Time (sec) required to return to the plain
paper fusing temperature)
1 - 60 10 10 10
X
9 COOL_DOWN_ENVELOPE
Cool-down time envelope (Time (sec) required to return to the plain
paper fusing temperature)
1 - 60 15 15 15
X
10 HL_UM THIN PAPER BW Thin paper BW-TH_UM
70 - 230 150 150 150
O
11 HL_UM THIN PAPER CL Thin paper COL-TH_UM
70 - 230 160 160 160
O
12 HL_UM THIN PAPER READY Thin paper Ready-TH_UM
70 - 230 140 140 140
O
13 HL_UM REC PAPER BW Recycled paper BW-TH_UM
70 - 230 165 175 175
O
14 HL_UM REC PAPER CL Recycled paper COL-TH_UM
70 - 230 170 180 180
O
15 HL_UM REC PAPER READY Recycled paper Ready-TH_UM
70 - 230 155 165 165
O
16
HPOWER_SET Power voltage setting
1:100V 2:120V 3:230V
1 - 3 123
O
TH_UM Fusing upper thermister (center) HL_UM Heater lamp upper
TH_LM Fusing lower thermister HL_LM Heater lamp lower
TH_E Fusing thermister (external heat roller) HL_E Heater lamp (external heat roller)
Group Destination
Group A Japan China AB_B -
Group B U.S.A. Canada Inch -
Group C Europe U.K. AUS AB_A
