MX-C250 SIMULATION 6 – 32
44-4
Purpose
Setting
Function (Purpose)
Used to set the conditions of the high den-
sity process control operation.
Section
Process
Operation/Procedure
1) Select an item to be set with Arrow keys.
2) Enter the set value with 10 keys.
3) Press [OK]/[START] key.
The set value in step 2) is saved.
NOTE:
Set the items to the default values unless a change is spe-
cially required.
44-6
Purpose
Adjustment
Function (Purpose)
Used to execute the high density process
control forcibly.
Section
Process
Operation/Procedure
When [OK]/[START] key is pressed, the adjustment is exe-
cuted automatically.
After completion of the adjustment, the adjustment result is
displayed. (Refer to the table below.)
If the adjustment is not executed normally, "ERROR" is dis-
played.
REG_R_LED_ADJ Registration sensor R adjustment abnor-
mality
REG_F_GRND F registration basis material reading
abnormality
REG_R_GRND R registration basis material reading
abnormality
Item/Display Content
Setting
range
Default
value
1 PCS TARGET Sensor target set value
1 - 255 204
2PCS ADJ LIM
Sensor adjustment target limit
value
1 - 255 8
3BELT G DIF
Effective difference between the
belt circuit substrate upper and
lower limit values
1 - 255 1
4 B_BK STD DIF
Bias (for black) Target calcula-
tion difference
0 - 255 0
5 B PAT INT Patch bias output interval
1 - 255 60
6Y TAR ID
Patch density standard value
(yellow)
1 - 255 45
7 M TAR ID
Patch density standard value
(magenta)
1 - 255 50
8 C TAR ID
Patch density standard value
(cyan)
1 - 255 50
9K TAR ID
Patch density standard value
(black)
1 - 255 45
10 HV BK_GR LIM
Patch position substrate light
receiving effective range value
1 - 255 60
11
LED ADJ
ROUGH
LED radiation quantity adjust-
ment rough 1step
1 - 255 5
12
LED ADJ
ROUGH
UPPER
LED radiation quantity adjust-
ment rough 1step execution
threshold level upper
1 - 255 240
13
LED ADJ
ROUGH
LOWER
LED radiation quantity adjust-
ment rough 1step execution
threshold level lower
1 - 255 140
14
K_PAT TAR-
GET UPPER 1
Simplified process control solid-
patch transition judgment to high
density process control upper
limitation 1 (K-patch)
1 - 255 10
15
K_PAT TAR-
GET LOWER 1
Simplified process control solid-
patch transition judgment to high
density process control lower
limitation 1 (K-patch)
1 - 255 10
16
K_PAT TAR-
GET UPPER 2
Simplified process control solid-
patch transition judgment to high
density process control upper
limitation 2 (K-patch)
1 - 255 15
17
K_PAT TAR-
GET LOWER 2
Simplified process control solid-
patch transition judgment to high
density process control lower
limitation 2 (K-patch)
1 - 255 15
18
K_HT TARGET
UPPER 1
Simplified process control half-
tone-patch transition judgment
to high density process control
upper limitation 1 (K-patch)
1 - 255 10
19
K_HT TARGET
LOWER 1
Simplified process control half-
tone-patch transition judgment
to high density process control
lower limitation 1 (K-patch)
1 - 255 10
Error name Error content
20
K_HT TARGET
UPPER 2
Simplified process control half-
tone-patch transition judgment
to high density process control
upper limitation 2 (K-patch)
1 - 255 15
21
K_HT TARGET
LOWER 2
Simplified process control half-
tone-patch transition judgment
to high density process control
lower limitation 2 (K-patch)
1 - 255 15
22
CL_PAT TAR-
GET UPPER 1
Simplified process control solid-
patch transition judgment to high
density process control upper
limitation 1 (CL-patch)
1 - 255 10
23
CL_PAT TAR-
GET LOWER 1
Simplified process control solid-
patch transition judgment to high
density process control lower
limitation 1 (CL-patch)
1 - 255 10
24
CL_PAT TAR-
GET UPPER 2
Simplified process control solid-
patch transition judgment to high
density process control upper
limitation 2 (CL-patch)
1 - 255 15
25
CL_PAT TAR-
GET LOWER 2
Simplified process control solid-
patch transition judgment to high
density process control lower
limitation 2 (CL-patch)
1 - 255 15
26
CL_HT TAR-
GET UPPER 1
Simplified process control half-
tone-patch transition judgment
to high density process control
upper limitation 1 (CL-patch)
1 - 255 10
27
CL_HT TAR-
GET LOWER 1
Simplified process control half-
tone-patch transition judgment
to high density process control
lower limitation 1 (CL-patch)
1 - 255 10
28
CL_HT TAR-
GET UPPER 2
Simplified process control half-
tone-patch transition judgment
to high density process control
upper limitation 2 (CL-patch)
1 - 255 15
29
CL_HT TAR-
GET LOWER 2
Simplified process control half-
tone-patch transition judgment
to high density process control
lower limitation 2 (CL-patch)
1 - 255 15
30
SP_PAT COEF
UPP DIF
Simplified process control den-
sity coefficient upper threshold
level
1 - 255 10
31
SP_PAT COEF
LOW DIF
Simplified process control den-
sity coefficient lower threshold
level
1 - 255 10
Result display Content description
COMPLETE Normal complete
ERROR Abnormal end
INTERRUPTION Forcible interruption
Details of error display Content description
CL_SEN_ADJ_ERR Color sensor adjustment abnormality
BK_SEN_ADJ_ERR Black sensor adjustment abnormality
K_HV_ERR K high density process control abnormality
C_HV_ERR C high density process control abnormality
M_HV_ERR M high density process control abnormality
Y_HV _ERR Y high density process control abnormality
TIMEOUT_ERR Time out
Item/Display Content
Setting
range
Default
value
