Sharp MX-C301W Technical Handy Guide

TROUBLE CODES
SHARP
54
A0
01
PCU ROM abnormality [MX-C301W]
02
SCU ROM abnormality [MX-C301W]
10
Colour profile error [MX-C301W]
15
Incompatible DSK Boot and program
firmware version [MX-C301W]
20
Firmware & EEPROM conflict (MFP)
[MX-C301W]
21
Firmware & EEPROM conflict (PCU)
[MX-C301W]
22
Firmware & EEPROM conflict (SCU)
[MX-C301W]
30
Machine configuration error [MX-C250/300]
C1
10
Main charger trouble (BK)
CE
00
Network communication error
01
Network controller trouble
02
FTP or Mail server is not found
03
Specified server does not correspond
during transmission
04
Invalid account/password (FTP server)
05
Invalid directory entered (FTP server)
06
Specified mail server (POP3) is not found
09
Email file size error
11
Scanner memory shortage
12
LDAP address number is exceeded
13
USB memory is not installed
14
USB memory write protect
15
Insufficient USB memory
16
USB memory I/O error
17
USB memory error (Other)
E7
01
MFP image data trouble.
03
HDD trouble [MX-C301W]
04
HDD-ASIC error [MX-C301W]
07
SD Card error [MX-C301W]
10
Shading trouble (Black correction).
11
Shading trouble (White correction).
14
CCD-ASIC communication error.
20
LSU BD(KC) detection error / LSU LD
deform error (K)
21
LSU LD deform error (C)
22
LSU LD deform error (M)
E7
23
LSU BD(MY) detection error / LSU LD
deform error (Y)
28
LSU - PCU communication error
29
LSU-ASIC frequency abnormality.
38
Zoran chip AD adjustment error
[MX-C250/300]
49
Watermark data error [MX-C301W]
50
Firmware & PWB combination error
[MX-C301W]
55
PCU PWB information sum error
[MX-C301W]
60
MFP combination error (Firmware/PWB)
[MX-C301W]
61
MFP-PCU combination error [MX-C301W]
65
MFP EEPROM sum check error
[MX-C301W]
80
MFP-SCU communication trouble.
90
MFP-PCU communication trouble.
91
Fax reception image data error
92
Copy image data error
93
Image data process error.
94
Image data process error (import data)
[MX-C301W]
95
Printer PWB DIMM memory check error
[MX-C301W]
96
MFP PWB DIMM memory check error
[MX-C301W]
EE
EC
Auto DV adjustment trouble.
EL
Auto DV adjustment trouble (over toned).
EU
Auto DV adjustment trouble (under toned).
F2
22
Discharge lamp trouble (K)
23
Discharge lamp trouble (C) [MX-C301W]
(CMY) [MX-C250/300]
24
Discharge lamp trouble (M) [MX-C301W]
25
Discharge lamp trouble (Y) [MX-C301W]
30
Power thermistor trouble [MX-C301W]
39
Process temperature sensor trouble
40
Toner density sensor trouble (K)
41
Toner density sensor trouble (C)
42
Toner density sensor trouble (M)
43
Toner density sensor trouble (Y)
45
Colour image density sensor trouble
47
Ozone duct thermistor trouble

Sharp MX-C301W Specifications

General

Print Technology	Laser
Print Speed	30 ppm
Max Print Resolution	600 x 600 dpi
Max Scan Resolution	600 x 600 dpi
Copy Speed	30 cpm
Max Copy Resolution	600 x 600 dpi
Fax Capability	Yes
Max Paper Capacity	800 sheets
ADF Capacity	50 sheets
Duplex Printing	Yes
Scanner Type	Color CIS
Standard Paper Capacity	250 sheets
Connectivity	USB, Ethernet, Wi-Fi
Mobile Printing	Yes
Display	7.0-inch color touch-screen LCD
Max Paper Size	8.5 x 14 inches
