MX-TR10 8 - 3
2-9. Insert the power cord into the outlet and turn the
main switch located on the left side of the copier
to the "ON" position.
2-10. Carry out separator unit installation setting.
1) Use the keys on the copier to execute simulation [26-1-1].
2) Press the [CA] key to exit the simulation.
2-11. Check the operation of the job separator.
1) Use the keys on the copier to execute simulation [3-4].
2) The separator tray will move up and down and then stop automati-
cally after simulation is complete.
Note: Step-out noise may be caused only at initial operation but it is not
a malfunction.
3) Press the [CA] key to exit the simulation.
Installation of MX-TR10 is now complete.
