Sharp MX-M200D Service Manual

MX-M200D SIMULATIONS 7-26
30 01 Paper sensor status display
Used to display the list of paper sensor status on the LCD. An active sensor is highlighted.
The display items and corresponding sensors are shown below.
When a multi-stage cassette is not installed as an option, the corresponding sensor name is not displayed.
41 01 Document size detection photo sensor check
Used to check the operation of the document sensor.
When this simulation is executed, the status of the document sensor is displayed.
An active sensor display is highlighted.
* For AB series, PD1-PD5; for inch series, PD1 - PD4.
02 Document size detection photo sensor detection level adjustment
When this simulation is executed, the detection level of the OC document size detection sensor is displayed.
(Real time display)
Place white paper of A3 or WLT on the document table and press [OK] key or [START] key with the OC
cover open.
When [START] key is pressed, "EXEC" is highlighted and the document detection level at that moment is
saved in the EEPROM. (The saved value is used as the reference for the following document size detection
control.)
The values are displayed in the range of 0 - 255.
0 (Black) - 255 (White)
The value in [ ] indicates the adjustment threshold value. "EXEC" is highlighted during execution.
Main
code
Sub
code
Contents Remark
Display : Corresponding sensor
POUT : Paper exit sensor
DPX : DUPLEX sensor
PIN : Paper entry sensor
MBEMP : Manual feed paper sensor
C1EMP : No. 1 tray paper sensor
C2EMP : No. 2 tray paper sensor
C3EMP : No. 3 tray paper sensor
C4EMP : No. 4 tray paper sensor
C2PSS : No. 2 tray paper feed sensor
C3PSS : No. 3 tray paper feed sensor
C4PSS : No. 4 tray paper feed sensor
Sim30-1 SENSOR
POUT DPX PIN
MBEMP C1EMP C2EMP
C3EMP C4EMP C2PSS
C3PSS C4PSS DRST
Sim41-1 PD SENSOR
OCSW PD1 PD2
PD3 PD4 PD5
OC cover open/close sensor status Document sensor status
OCSW Open Close PD1 - PD5 Document NO Document
YES
Highlighted Normal display Normal display Highlighted
Execution window Sensor position for AB series Sensor position for Inch series
Sim41-2 PD SENSOR
OCS
1[128] 200
3[128] 200
5[128] 200
2[128] 200
4[128] 200
1
2
3
54
1
2
43
OCSW Original cover status
Open: Highlighted
Close: Normal display
1 - 5 PD sensor detection level
