MX-M316N SIMULATION 6 – 64
55
55-1
Purpose
(Do not use this function unless specially
required.)
Function (Purpose)
Used to set the specifications of the engine
control operations. (SOFT SW)
Section
Operation/Procedure
55-2
Purpose
(Do not use this function unless specially
required.)
Function (Purpose)
Used to set the specifications of the scan-
ner control operation. (SOFT SW)
Section
Operation/Procedure
55-3
Purpose
(Do not use this function unless specially
required.)
Function (Purpose)
Used to set the specifications of the control-
ler operation. (SOFT SW)
Section
Operation/Procedure
55-10
Purpose
Adjustment/Setting
Function (Purpose)
Used to set the special stamp text. (Taiwan
only)
Section
Operation/Procedure
1) Select an item to be set (digit, color, type) with the scroll key.
2) Enter the value corresponding to the setting item with 10-key.
3) Press [OK] key. (The set value is saved.)
Input value
56
56-1
Purpose
Backup
Function (Purpose)
Used to transport data between HDD - MFP
PWB SRAM/EEPROM. (Used to repair the
PWB.)
Section
Operation/Procedure
1) Select a target content of data transfer.
2) Press [EXECUTE] key and press [YES] key.
Data transfer of the item selected in procedure 1) is executed.
When the operation is completed normally, "COMPLETE" is
displayed. In case of an abnormal end, "ERROR" is displayed.
Item/Display Content
Setting
range
Default
value
A 1ST DIGIT First digit (left edge) 1 - 90 1
B 2ND DIGIT Second digit
C 3RD DIGIT Third digit 32 [blank:
20H]
D 4TH DIGIT Fourth digit 65 - 90
[Alphabet:
41H("A) -
5AH("Z")]
E 5TH DIGIT Fifth digit 48 - 57
[Numeral:
30H("0") -
39H("9")]
F 6TH DIGIT Sixth digit (right
edge)
G COLOR K Color specification
input
00
C1
M2
Y3
R4
G5
B6
H TYPE PATTERN
1
Print
com-
posing
method
Edging
type
01
PATTERN
2
OR
process
type
1
PATTERN
3
No-
delete-
compo-
sition type
2
Print Blank A B C E F G
Input value32656667697071
Print H I J K L M N
Input value72737475767778
Print O P Q R T U V
Input value79808182848586
Print W X Y Z 0 1 2
Input value87888990484950
Print 356789
Input value515354555657
EEPROM -> HDD Transfer from EEPROM to HDD
HDD -> EEPROM Transfer from HDD to EEPROM
Item/Display Content
Setting
range
Default
value
