Sharp MX-M356N Service Manual

MX-M316N SPECIFICATIONS 2 – 1
MX-M316N
Service Manual
[2] SPECIFICATIONS
1. Basic specifications
A. Engine Specification
B. Engine speed (ppm)
Tray 1 - 4
Manual paper feed
C. Printable area
D. Engine resolution
*: The dither and error diffusion methods using 8bit input will be
performed.
E. Scanner section
(1) Resolution/Gradation
(2) Document table
Photo conductor OPC (Diameter: 30mm)
Recording Electronic photo (Laser)
Development Dry-type dual-component magnetic
brush development
Charging Charged saw-tooth method
Transfer Transfer roller
Separation Separation claw method
Cleaning Counter blade
Fusing Heat roller
Waste toner disposal Toner cartridge collection
Toner supply during operation N/A
Outer color Pastel white (Natural wave pattern)
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 15 17
20
11x17 14 17
19
8K 16 19
21
B4, 8.5x13, 8.5x13.5, 8.5x13.4, 8.5x14 16 20
22
A4, B5, 8.5x11, 16K, A5R, 5.5x8.5R 26 31
35
A4R, 8.5x11R, 16KR 18 24
27
B5R 21 24
30
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 14 17
18
11x17 14 16
17
8K 15 18
19
B4, 8.5x14 16 19
20
8.5x13 17 20
22
8.5x13.5, 8.5x13.4 16 19
21
A4, B5, 8.5x11, 16K, A5R, 5.5x8.5R,
A5, 5.5x8.5
23 27 29
A4R, 8.5x11R, 7.25x10.5R 19 22 24
16KR 19 22 25
B5R 21 24
26
Extra 14 16
17
Custom 14 16
17
A3 Wide N/A 16K 191 x 263mm
A3 293 x 413mm 12 x 18 N/A
B4 253 x 357mm 11" x 17" 275 x 425mm
A4 206 x 290mm 8.5" x 14" 212 x 349mm
B5 178 x 250mm 8.5" x 13" 212 x 323mm
A5 144 x 203mm Executive 180 x 260mm
Postcard 92 x 140mm 8.5" x 11" 212 x 272mm
8K 266 x 383mm 5.5" x 8.5" 136 x 209mm
8.5x13.5 212 x 336mm 8.5" x 13.4" 212 x 333mm
Custom Min.: 96mm x 141mm; Max.: 297mm x 432mm
Max. range AB: 416x293mm (600dpi: 9826dot x 6920dot)
Inch: 428x275mm (600dpi: 10110dot x 6496dot)
Void Area Top 1 to 4mm
Bottom 1 to 5mm
Front/Rear Total 6mm or less
Image Loss Top 4mm or less
Front/Rear Total 6mm or less
Image missing
width
Top 4mm or less, Bottom 4mm or less,
Front/Rear Total 6mm or less
Resolution Copy Writing
600 x 600dpi
Print Writing
600 x 600dpi
1,200 x 600dpi (PCL/PS)
Gradation *
(256 levels)
Copy Writing
600 x 600dpi x 1bit
Print Writing
Sharp Advanced Printing Language:
600 x 600dpi x 1bit
PCL:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
PS:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
Scanning
Resolution (dpi)
Monochrome
Platen 600 x 600dpi
600 x 400dpi
600 x 300dpi (default)
RSPF 600 x 600dpi
600 x 400dpi (default)
Exposure lamp White LED
Reading gradation 10bit
Output gradation BW: 1bit
Grayscale: 8bit
Full Color: each color RGB 8bit
Type Document table fixed system (Flat bed)
Scanning area 297 x 432mm
Original standard
position
Left rear reference
Detection Yes
Detection size Automatic detection (Detection types can be
changed in the system settings)
Dehumidifying
heater
(Scanner section)
Supplied as a service parts
1
: ‘15/Aug.
1
1

Sharp MX-M356N Specifications

General

Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
ISO A-series sizes (A0...A9)	A3, A4, A6
Maximum ISO A-series paper size	A3
Grayscale levels	256
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Print technology	Laser
Maximum resolution	1200 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	35 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	4 s
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	2100 sheets
Faxing	Mono faxing
Fax memory	1024 MB
Wi-Fi	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1440 W
Power consumption (off)	0.1 W
Power consumption (sleep)	1 W
Power consumption (standby)	63 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	75000 pages per month
Standard interfaces	USB 2.0
Optional connectivity	Ethernet

Weight and Dimensions

Depth	617 mm
Width	620 mm
Height	830 mm
