8. Switch
A. MX-M316N/M266N/M315N/M315U/M356N/
M356U
B. MX-M265N/M265U
No. Name Code Function and operation
1 Power switch MAIN SW Turns ON/OFF the main
power source.
2 Side door/Front
cover switch
DSWR/
DSWF
Side door/Front cover open
detection
3 2nd tray (paper tray)
detection
C2SS 2nd tray (paper tray) empty
detection
4 2nd side door cover
switch
DSW_C2 Side door open detection
2
4
3
1
No. Name Code Function and operation
1 Power switch MAIN SW Turns ON/OFF the main
power source.
2 Side door/Front
cover switch
DSWR/
DSWF
Side door/Front cover open
detection
2
1
1
