FINISHER AND SADDLE STITCH FINISHER
3-3
3
*For index paper, equivalent to 140-lbs.
* For index paper, equivalent to 140-lbs.
Specifications are subject to change for improvement without notice.
■ Supplies
The finisher and saddle stitch finisher require the following staple cartridge:
● Staple cartridge for finisher
(approx. 5,000 per cartridge
X 3 cartridges)
SF-SC11
● Staple cartridge for saddle
stitch finisher (approx. 2000
per cartridge X 3 cartridges)
AR-SC3
Paper size
Upper paper tray/Middle paper tray:
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2"
x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-
1/2" x 8-1/2"R, A3, B4, A4, A4R, B5, B5R,
A5R
Upper paper tray/Middle paper tray:
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x
11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2"
x 8-1/2"R, A3, B4, A4, A4R, B5, B5R, A5R
Lower tray:
11" x 17", 8-1/2" x 11"R, A3, B4, A4R
Paper weight
Upper paper tray/Middle paper tray:
16 to 68* lbs. (60 to 256 g/m
2
)
Upper paper tray/Middle paper tray/Lower tray:
16 to 68* lbs. (60 to 256 g/m
2
)
Paper full detection Both upper and lower tray Upper, middle and lower tray
Paper sizes for which
offset is possible
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5
Allowed paper sizes for
stapling
Upper paper tray/Middle paper tray:
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2"
x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5
Upper paper tray/Middle paper tray:
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x
11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5
Lower tray:
11" x 17", 8-1/2" x 11"R, A3, B4, A4R
Maximum number of
sheets for stapling
See "Staple sort mode" on 3-4 page
Stapling positions 1 place at back, 1 place at back (diagonal), one place at front (diagonal), 2 places
Paper conveying Center reference
Power supply Supplied from machine
Dimensions
When tray is folded up: 25-33/64" (W) x 24-13/16" (D) x 45-9/32" (H)
(648 mm (W) x 630 mm (D) x1150 mm(H))
When tray is extended: 30-7/16" (W) x 24-13/16" (D) x 45-9/32" (H)
(773 mm (W) x 630 mm (D) x1150 mm(H))
Not including stopper (1-37/64" (40 mm)) when attached to machine
Weight Approx. 113 lbs. (Approx. 51 kg) Approx. 157
lbs.
(Approx. 71 kg)
Overall dimensions when
attached to machine
30-7/16" (W) x 24-13/16" (D) (Separation from machine 15-3/4")
(773 mm (W) x 630 mm (D) (Separation from machine 400 mm))
Name Punch module (AR-PN4B)
Hole punching 3 holes
Allowed paper sizes for
punching
11" x 17", 8-1/2" x 14", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, A3, B4, A4, A4R, B5,
B5R
Page weight 16 to 68* lbs. (60 to 256 g/m
2
)
Power supply Supplied from finisher / saddle stitch finisher
Dimensions 3-3/4" (W) x 22-1/16" (D) x 6-45/64" (H) (95 mm (W) x 560 mm (D) x 170 mm (H))
Weight Approx. 7.8 lbs. (Approx. 3.5 kg)
NOTES
● The following papers cannot be stapled and punched:
Special papers such as transparency film and label sheets
● If mixed paper sizes are selected for stapling jobs, stapling will be automatically canceled.
