UNPACKING & LOCK REMOVAL
Use Skid Slopes [UKOG-0367FCZZ] to remove device from shipping pallet.
Operation Panel installation.
Remove Tray Lift Lock Plates.
Release Fusing Pressure.
DEVELOPER SET-UP
Sim 25-02 Auto Developer Adjustment - Select K.
Toner Installation must be performed after Auto Developer Adjustment is
completed.
**For optimum image quality & performance, it is recommended to setup &
install developer at the customer site.
TONER INSTALLATION & REPLENISHMENT
Install K Toner Cartridge.
PRODUCT ACTIVATION & FIRMWARE UPGRADE
Activation of Optional Product(s):- System Settings – Product Key.
Sim 22-05 Check Firmware version(s):- Upgrade to latest version.
INITIAL SETUP
Sim 21-01 Maintenance Cycle Setting:- Set PM Counter = 500k,
Sim 26-02 LCC Installation (Paper Size).
Sim 26-06 Machine Destination.
Sim 26-35 Set Multi Error Counter:- Set to 1 (Multi Count).
Sim 26-52 Non Printed Paper Counter Set-up.
Sim 40-12 Multi Purpose Tray (Tray 4) Adjustment/Calibration.
Sim 55-03 Process Mixed Original Printing for Duplex:-
SSW 3-6, 0 = Disable, 1 = Enable.
System Settings: Adjust Date/Time (Inc. Daylight Saving setting).
Set cassette size by adjusting the guides in the cassette.
Paper Size & Type Setting:- System Settings – Paper Tray Settings.
PRINT ENGINE IMAGE SKEW
Sim 64-02 Image Writing Adjustment:-
Select A=5, B=1, C=254, D=255, E=1, F=1, G=8.
