PRINT ENGINE IMAGE SKEW
Sim 64-02 Image Writing Adjustment:-
Select A=5, B=1, C=254, D=255, E=1, F=1, G=8.
PRINT IMAGE POSITION & MAGNIFICATION
Automatic Adjustment:-
Sim 50-28 BK MAG ADJ (Main Scan Mag).
SETUP/PRINT ADJ (Lead, Offset or All).
Manual Adjustment:-
Sim 50-10 BK MAG (inside dimension) to 240mm.
Sim 50-10 Image Off Centre Adjustment.
Sim 50-05 Printer Lead Edge & Void Adjust.
ENGINE & PRINTER HALF TONE CALIBRATION
Sim 46-74 Engine & Printer Half Tone Calibration Select FACTORY Mode.
COPY IMAGE QUALITY
Check Image Quality (Copy Mode) – Density, Magnification, Lead Edge & Void.
If NG, perform the following adjustments as required:-
Sim 46-02 Copy Density Adjust. (B/W).
Sim 46-09 DSPF Copy Density Adjust.
Sim 50-28 OC ADJUST (Lead, Offset & Mag).
SPF ADJ:(Lead, Offset & Sub scan).
Manual Adjustment (Magnification, Lead Edge, Void, Off Centre etc):-
Sim 48-01 Magnification Adjustment (OC & SPF).
Sim 50-01 Lead/Rear Edge, Loss & Void Adjust.
Sim 50-06 DSPF Lead Edge Adjust.
Sim 50-12 OC & SPF Off Centre Adjust.
Check DSPF Level Adjustment.
DSPF Skew Adjustment:- Use UKOG-0264FCZZ DSPF D-Chart
PRINT IMAGE QUALITY
Check Image Quality (Print Mode) – Density:-
Sim 64-05 PCL Density Test Page.
Sim 64-06 PS Density Test Page.
