MOUSE/Adjustment buttons (P/R/O/Q)
35, 39
For moving the computer cursor when with the
USB connection (using a USB cable or the
optional remote receiver).
For selecting and adjusting menu items.
•
•
8
L-CLICK/EFFECT button
35, 33
For the Left click when with the USB
connection (using a USB cable or the optional
remote receiver).
For changing the pointer or spot area.
•
•
9
KEYSTONE button
29
For entering the Keystone Correction
mode.
10
AUTO SYNC button
34, 50
For automatically adjusting images when
connected to a computer.
11
FUNCTION button
53
For operating and executing a function
assigned to “FUNCTION Button”.
12
ECO+QUIET button
33
For lowering the noise of the cooling fan
and extending the lamp life.
13
FREEZE button
34
For freezing images.
14
AV MUTE button
30
For temporarily displaying a black screen
and turning off the sound.
15
VOL +/– (Volume) buttons
30
For adjusting the speaker sound level.
16
SPOT button
33
For displaying the spotlight.
17
ENTER button
39
For setting items selected or adjusted on
the menu.
18
R-CLICK/RETURN button
35, 39
For the Right click when with the USB
connection (using a USB cable or the optional
remote receiver).
For returning to the previous menu screen
during menu operations.
•
•
19
MENU button
39
For displaying adjustment and setting
screens.
20
RESIZE button
31
For switching the picture size (NORMAL,
16:9, etc.).
21
3D MODE button
See the OPERATION MANUAL FOR
STEREOSCOPIC 3D PROJECTION
provided separately.
22
PICTURE MODE button
34
For selecting the appropriate picture.
23
ON button
26
For turning the power on.
1
STANDBY button
26
For putting the projector into the Standby
mode.
2
BREAK TIMER button
33
For displaying the break time.
4
MAGNIFY buttons
34
For enlarging/reducing part of the image.
5
PAGE UP/PAGE DOWN buttons
35
Same as the [Page Up] and [Page Down]
keys on a computer keyboard, when with
the USB connection (using a USB cable or
the optional remote receiver).
6
POINTER button
33
For displaying the pointer.
7
Part Names and Functions (Continued)
Numbers in Z refer to the main pages in this operation manual where the
topic is explained.
INPUT buttons (
/
)
30
For switching Input mode.
3
