Computer Compatibility Chart
Computer
• Multiple signal support
Horizontal Frequency: 15-110 kHz,
Vertical Frequency: 45-85 Hz,
Pixel Clock: 12-170 MHz
Sync signal: Compatible with TTL level
• Compatible with sync on green signal
PC/MAC Mode Resolution
Horizontal frequency
[kHz]
Vertical
frequency[Hz]
Analog
Support
Digital
Support
Display
PC
VGA
640 × 400
27.0 60
✔
Upscale
31.5 70
✔
37.9 85
✔
720 × 400
27.0 60
✔
31.5 70
✔✔
37.9 85
✔
640 × 480
26.2 50
✔
31.5 60
✔✔
34.7 70
✔
37.9 72
✔✔
37.5 75
✔✔
43.3 85
✔
SVGA 800 × 600
31.3 50
✔
35.2 56
✔✔
37.9 60
✔✔
46.6 70
✔
48.1 72
✔✔
46.9 75
✔✔
53.7 85
✔
XGA 1024 × 768
40.3 50
✔
TRUE
48.4 60
✔✔
56.5 70
✔✔
60.0 75
✔✔
68.7 85
✔
WXGA
1280 × 720 45.0 60
✔✔
Intelligent
Compression
1280 × 768 47.8 60
✔
✔
*
1280 × 800
49.7 60
✔
✔
*
62.8 75
✔
1360 × 768 47.7 60
✔
✔
*
1366 × 768 47.8 60
✔
✔
*
WXGA+ 1440 × 900 55.9 60
✔
SXGA
1152 × 864
55.0 60
✔✔
66.2 70
✔
67.5 75
✔✔
1280 × 960
60.0 60
✔✔
75.0 75
✔
1280 × 1024
64.0 60
✔✔
80.0 75
✔✔
SXGA+ 1400 × 1050
64.0 60
✔✔
65.3 60
✔✔
WSXGA+ 1680 × 1050 65.3 60
✔
UXGA 1600 × 1200 75.0 60
✔
MAC 13” VGA 640 × 480 34.9 67
✔
Upscale
MAC 16” SVGA 832 × 624 49.7 75
✔
MAC 19” XGA 1024 × 768 60.2 75
✔
TRUE
MAC 21” SXGA 1152 × 870 68.7 75
✔
Intelligent
Compression
*Switch to Plug-and-Play data. (See page 37.)
Optimum image quality will be achieved by matching your computer's output resolution to the
resolution that corresponds to “TRUE” in the “Display” column shown above.
When “Screen resolution” of the computer is different from the resolution displayed on the projected
image, follow the procedures shown below.
– Refer to “Select the resolution” for “Data image is not centered” on the Help menu and select the
same resolution as the resolution in “Screen resolution” of the computer.
–
Depending on the computer you are using, the output signal may not be faithful to the “Screen resolution”
adjustment. Check the settings of the computer's signal output. If the settings cannot be changed, it is
recommended that the resolution be set to the one that corresponds to “TRUE” in the “Display” column.
•
•
Note
DTV
Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Analog
Support
Digital
Support
Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Analog
Support
Digital
Support
480
I
15.7 60
✔
720P 45.0 60
✔✔
480P 31.5 60
✔✔
1035
I
33.8 60
✔
540P 33.8 60
✔
1080
I
28.1 50
✔✔
576
I
15.6 50
✔
1080
I
33.8 60
✔✔
576P 31.3 50
✔✔
1080P 56.3 50
✔✔
720P 37.5 50
✔✔
1080P 67.5 60
✔✔
