Sharp Plasmacluster KC-C70U User Manual

E-10
4
3
Fill in the usage
start date on the
Date Label.
Use the usage start date
as a guide for when the
lters should be replaced.
Date Label
Installing the filter backwards
will affect the performance of
the unit.
Unplug the unit before installing
or adjusting the lters.
PREPARATION FOR USE
2
1
Remove the Back Panel.
Install the lters
Install the True HEPA Filter.
To maintain the quality of the lters, they are packed in plastic bags and placed in the
unit. Be sure to remove the lters from the plastic bags and replace the lters in the
unit before initial use.
1
Gently push down on the
tabs, then tilt and remove the
back panel.
Remove the lters
2
Remove the Wash-
able Deodorizing Filter
(black) and True HEPA
Filter (white) from the
plastic bags.
Back Panel
True HEPA Filter
Washable
Deodorizing
Filter
True HEPA Filter
Insert the Back Panel’s 2 bottom tabs
(left and right) into the small holes in the
unit, and slide the Washable Deodoriz-
ing Filter between the True HEPA Filter
and the Back Panel.
Gently push in
the upper tabs
(left and right) to
lock in place.
FILTER INSTALLATION
1
2
Tabs on the top
Washable Deodorizing Filter
Back Panel
Bottom tabs
Upper tabs
Please make sure that the True HEPA Filter
is placed in proper orientation.
KC-C70U_Eng_N.indd 12 07.11.7 1:19:40 PM
